Port output gain
Use this option to set the level of gain on the output from the Base station
Microphone Echo Cancellation
Use this option to improve audio quality by reducing microphone echo.
 Select the Mic Echo Cancellation check box.
Master Volume Operation
If checked rotaries A and B both adjust the beltpack master volume level. If not
checked rotary A adjusts the volume for the assignment on Key A and rotary B
adjusts the volume for the assignment on Key B.

10.4.6 Beltpack alarm options

The following sections describe how to configure the beltback alarm options. The
beltpack issues alarms when:
 The beltpack battery is low
 The beltpack is out of antenna reception range
 The beltpack receives an incoming call
Setting the battery alarm mode
Use this option to determine what kind of alarm the beltpack issues.
From the Battery Alarm Mode list, select from the following options:
 Vibrate & Audio - the beltpack vibrates and issues an audible alarm
 Vibrate only - the beltpack vibrates
 Audio only - the beltpack issues an audible alarm
 Off - the beltpack issues no alarms
Note: The factory default is Vibrate & Audio
Setting the low battery alarm threshold
Use this option to determine the battery level at which the beltpack issues a low
battery alarm.
 From the Low Battery Threshold list, select a low battery threshold
level. The settings run from 0% to 100%. The factory default is 25%.
Setting the call alert mode
Use this option to determine what kind of alarm the beltpack issues when it
receives an incoming call.
From the Call Alert Mode list, select from the following options:
Page 137
User Guide | FreeSpeak II™ Base station version
