3)
From the Name field, select a beltpack slot. See 10.4.1 Selecting the
beltpack to register or edit.
Note: You can also change the name of the beltpack by over typing the
4)
Select Register. The Configuration Editor now sends the system number
and carrier mask information to the beltpack, and also stores the serial
number of the beltpack in the Base station configuration.
If the program connects successfully with the beltpack, the BP ID field
displays its ID number.
Note: You can reassign the beltpacks to different slots on the same Base
10.4.3 Viewing beltpack registration information
1)
To view a summary of the labels and serial numbers of the beltpacks, click
Overview. The following screen is an example:
2)
Click OK to close the Overview window.
10.4.4 Viewing beltpack properties
The Set Properties button opens the beltpack properties screen. This allows the
beltpack defaults to be configured and downloaded to a beltpack as part of the
map. Beltpack setting defaults can be stored and restored in the editor and
factory default settings recalled. To view the beltpack properties:
Page 134
value in the Name field.
station using the Configuration Editor.
Figure 10-8 Beltpack overview
User Guide | FreeSpeak II™ Base station version
