Setting The Microphone Type; Setting The Microphone Echo Cancellation; Configuring The Beltpack Display And Leds - ClearCom FreeSpeak II User Manual

8.4.1

Setting the microphone type

Use this setting to specify the type of microphone you are using. You can also
allow the beltpack to automatically detect what kind of microphone is present.
1) To enter the beltpack menu, press and hold the Menu key.
2) Use the rotary and Menu Select keys to select Settings > Mic Options
> Mic Type.
3) Use either rotary control to select between:
4) To confirm the selection and exit the menu screen, press the Menu
Select key (D).
Note: If automatic headset detection is ON:
 Dynamic headset is detected if microphone impedance is between 90 –
320 Ohms
 Electret headset is detected if microphone impedance is between 1.3 – 6.5
kOhms.
8.4.2

Setting the microphone echo cancellation

Use this setting to improve the microphone audio quality.
1) To enter the beltpack menu, press and hold the Menu key.
2) Use the rotary and Menu Select keys to select Settings > Mic Options
> Echo Cancellation.
3) Use either rotary control to select between:
4) To confirm the selection and exit the menu screen, press the Menu
Select key.
8.5

Configuring the beltpack display and LEDs

You can configure the following display options:
Page 106
 Automatic (default)
 Electret
 Dynamic Unbalanced
 On
 Off (default)
User Guide | FreeSpeak II™ Base station version
