Technical Information

Specifications

Mechanical characteristics

Electrical characteristics

JS6000 Joystick Base
Mechanical
Shaft mechanical angle limits
Shaft maximum overload
Shaft maximum operating load
Shaft maximum downward loading 2450 N [550.76 lbf]
Shaft maximum torques
Base mechanical life (X and Y axis
only)
Base only mass
Breakout load on axis
Medium duty spring
Heavy duty spring
Load at full deflection
Medium duty spring
Heavy duty spring
Potentiometer sensor with analog output
Supply voltage (Vs)
Maximum survival voltage
Maximum wiper current
Maximum load current
Center tap/switch alignment
Potentiometer electrical angle
Center tap angle
Insulation resistance at 50 Vdc
Minimum load impedance
Potentiometer output options
Minimum voltage Maximum voltage
(% Vs) (% Vs)
10 ± 2 90 ± 2
25 ± 2 75 ± 2
10 ± 2 90 ± 2
25 ± 2 75 ± 2
520L0760 • Rev 1102 • November 2015
± 20˚
5 cycles only at 490 N [110.15 lbf] measured 130 mm [5.12 in] above
mounting surface
390 N [87.67 lbf] measured 130 mm [5.12 in] above mounting surface
15 N.m [11.06 lbf.ft]
> 7.5 million operating cycles
0.75 kg [1.65 lbf]
6 to 8.5 N [1.349 to 1.911 lbf]
12 to 19 N [2.698 to 4.271 lbf]
15 to 23 N [3.37 to 5.17 lbf]
31 to 47 N [6.97 to 10.57 lbf]
9 to 36 Vdc
36 Vdc
5 mA
200 mA resistive
Within 0.5˚
± 18˚
± 2.5˚
> 50 MΩ
1 MΩ recommended
Switch track angle Resistance
(°) (kΩ)
± 1.5 1.6 to 2.4
± 1.5 2.2 to 3.6
± 5 1.6 to 2.4
± 5 2.2 to 3.6
Model code order
character
R
Q
S
T
41
