Electrical Installation

JS6000 Analog Output
Product overview

Electrical specifications

6 | © Danfoss | May 2017
JS6000 potentiometer sensor with analog output
Supply voltage (Vs)
Maximum survival voltage
Maximum wiper current
Maximum load current
Center tap/switch alignment
Potentiometer electrical angle
Center tap angle
Insulation resistance at 50 Vdc
Potentiometer output options
Minimum voltage Maximum voltage
(% Vs) (% Vs)
10 ± 2 90 ± 2
25 ± 2 75 ± 2
10 ± 2 90 ± 2
25 ± 2 75 ± 2
Dual potentiometer output
Minimum voltage Maximum voltage
(% Vs) (% Vs)
10 ± 2 90 ± 2
JS6000 Hall effect sensor with analog output
Supply voltage (Vs)
Maximum survival supply voltage
Maximum current draw (base only)
Minimum output voltage
Center voltage
Maximum output voltage
< 36 Vdc
36 Vdc
5 mA
200 mA resistive
Within 0.5˚
± 18˚
± 2.5˚
> 50 MΩ
Switch track angle Resistance (KΩ)
(°)
± 1.5 1.6 to 2.4
± 1.5 2.2 to 3.6
± 5 1.6 to 2.4
± 5 2.2 to 3.6
Switch track angle Resistance (KΩ)
(°)
± 1.5 1.6 to 2.4
5 ± -0.5 Vdc
5 Vdc
90 mA
6% to 14% Vs
48% to 52% Vs
86% to 94% Vs
Model code order
character
RR
QQ
SS
TT
Model code order
character
UU
BC00000013en-US | 0201
