Technical Information
JS120 Single Axis Fingertip Joystick

Product specifications

Electrical characteristics

Mechanical characteristics

© Danfoss | December 2016
Electrical characteristics
Sensor type
Electrical angle of movement center return
Electrical angle of movement end return
Total track resistance
Maximum supply voltage (Vs)
Maximum wiper current
Maximum power dissipation
Wiper circuit impedance
Output voltage
Resolution
Center tap voltage (no load)
Center tap angle (center return)
Insulation resistance
Load resistance minimum
Load current maximum
Output voltage curve
90%
50%
10%
+Y
Mechanical characteristics
Description
Breakout force (at lever tip)
Operating force (at tip, full deflection)
Maximum allowable force
Lever operating angle
Lever action
Expected life
Weight
Potentiometric
28° ± 1°
Start 2° ± 1°, end return full angle 56° ± 1°
5 kΩ (± 20%)
35 Vdc
5 mA (non-destructive)
0.25 W at 20°C [68°F]
200 kΩ minimum
10 to 90% Vs
25 to 75% Vs
Infinite
50% Vs ± 2%
± 2.5° either side of center
(± 1° tolerance)
> 50 MΩ at 500 Vdc
10 kΩ
2 mA resistive
-Y
kwa1390403298242
Short lever
3.1 N [0.70 lbf]
5.1 N [1.15 lbf]
50 N [11.24 lbf]
30° ± 1° center return
60° ± 1° end return
Self centering or end return
> 5 million cycles
0.045 kg [0.099 lb]
Long lever
2.3 N [0.52 lbf]
3.4 N [0.76 lbf]
35 N [7.87 lbf]
520L0877 | BC00000075en-US0303 | 11
