Installation Guide
Sealing of holes in Prof1
PVRE and PVRET bases
Sealing kit:
The sealing kit is for more types of plastic covers used for Prof1, PVRE and PVRET.
Part A1 to C3 is for tightening holes in the plastic cover.
D1 is for types with SUB-D connector.
E1 to E4 is for types with wired connectors.
A1
B1
A2
E1
© Danfoss A/S, 2014-03
C1
B2
C2
C3
E2
11078864 • Rev CC • Mar 2014
D1
E3
E4
1
