Technical Information
JS2000 Joystick

Product specifications

Mechanical characteristics

14 | © Danfoss | May 2017
XY Axis
Shaft operation force (applied at top of grip)
Breakout
Operating
Maximum allowable
Shaft mechanical angle
Single axis option
Round gate, XY option
Square and Diamond gate, XY
option
Cross and plus gate, XY option
Expected life
Expected life
Weight
Weight
Z Axis
Operating torque
Breakout
Operating
Maximum allowable
Mechanical angle
Mechanical angle
Expected life
Expected life
1 N (0.22 lbf) nominal
2 N (0.45 lbf) nominal, full deflection
300 N (67.44 lbf) XY option,
195 N (43.84 lbf) XYZ option
± 20° forward/reverse
± 20°
± 20° to corners, ± 14° to flats
± 20° at extent of axes
15 M operations
90 g (0.20 lb) base without grip
0.04 N.m (0.03 ft.lb)
0.06 N.m (0.04 ft.lb)
1.0 N.m (0.74 ft.lb)
± 20°
5 M operations
520L0876 | BC00000073en-US0102
