- Page 1 Electrical Installation Joystick JS7000 Analog and CAN Output powersolutions.danfoss.com...
- Page 2 Electrical Installation JS7000 Analog and CAN Output Revision history Table of revisions Date Changed May 2017 Updated to Engineering Tomorrow design 0201 July 2014 Converted to Danfoss layout May 2012 Addition of CAN+ June 2011 First edition L1105361 | 0201 ©...
-
Page 3: Table Of Contents
Electrical Installation JS7000 Analog and CAN Output Contents Literature references JS7000 Analog and CAN Output literature references....................... 4 Latest version of technical literature............................4 Product overview Product image....................................5 Theory of operation..................................5 Electrical specifications.................................. 6 Electrical installation Pinout........................................7 Digital and proportional................................7 Digital outputs rocker options............................... -
Page 4: Literature References
Electrical Installation JS7000 Analog and CAN Output Literature references JS7000 Analog and CAN Output literature references Literature title Description Literature number JS7000 Joystick Technical Information Complete product electrical and L1125277 mechanical specifications JS7000 Function Blocks User Manuals Compliant function block set-up... -
Page 5: Product Overview
JS7000 Analog and CAN Output Theory of operation Danfoss JS7000 joysticks are general purpose mobile machine control joysticks. They are available in a Y and an XY axis configuration and support four grip options. JS7000 joysticks support two electrical output options: Analog and Controller Area Network (CAN). -
Page 6: Electrical Specifications
Electrical Installation JS7000 Analog and CAN Output Product overview Electrical specifications Electrical Sensor type Hall Effect with redundant sensors Resolution Infinite Supply voltage Analog 5 ± 0.5 Vdc CAN with redundant analog 9 to 60 Vdc outputs CAN+ 9 to 60 Vdc... -
Page 7: Pinout
Electrical Installation JS7000 Analog and CAN Output Electrical installation Pinout Digital and proportional Digital includes trigger, push-button, and rocker. Proportional includes roller and slider. Grip trigger switch Grip backside Grip faceplate Digital outputs rocker options Grip faceplate example Grip position 3 example... -
Page 8: Pinout Connections Examples
Electrical Installation JS7000 Analog and CAN Output Electrical installation Pinout connections examples Analog grip pinout connections example CAN and CAN+ minimum pinout connections example Signal number Description Signal number number number Digital1 Faceplate push-button 1 Battery Ground Digital6 Back side push-button 6... -
Page 9: Mating Connector
Danfoss ordering number Mating connector with 400 mm 11012646 (15.75 in) wire harness The Danfoss mating connector with wire harness features a fully assembled connector with an unterminated wire harness. L1105361 | 0201 | 9 © Danfoss | May 2017... -
Page 10: Danfoss | May
Electrical Installation JS7000 Analog and CAN Output L1105361 | 0201 10 | © Danfoss | May 2017... - Page 11 Electrical Installation JS7000 Analog and CAN Output L1105361 | 0201 | 11 © Danfoss | May 2017...
- Page 12 Phone: +86 21 3418 5200 Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products already on order provided that such alterations can be made without changes being necessary in specifications already agreed.
