- Page 1 Technical Information Joysticks JS120 Single Axis Fingertip Joystick powersolutions.danfoss.com...
- Page 2 Technical Information JS120 Single Axis Fingertip Joystick Revision history Table of revisions Date Changed December 2016 Corrected pinout drawing 0303 April 2016 Updated to Engineering Tomorrow design 0302 November 2015 Converted to Danfoss layout 0301 July 2009 Corrected connector pin assignments and added output voltage curve February 2007 Lever length options;...
-
Page 3: Table Of Contents
Technical Information JS120 Single Axis Fingertip Joystick Contents Overview Description......................................4 Features and options..................................4 Product configuration model code Model code summary..................................5 Center tap ..................................... 6 Padding resistors ..................................6 Position switches..................................6 Product installation Dimensions and mounting................................7 Connector pin assignments................................8 Mating connector details................................8... -
Page 4: Description
JS120 less susceptible to unintentional operation and the minimum under-panel footprint makes it ideal for mounting in panels and operator arm rests. The JS120 is sealed to IP 66 above panel to enable it to operate in extreme environments. -
Page 5: Product Configuration Model Code
JS120 Single Axis Fingertip Joystick Product configuration model code The product configuration model code specifies particular features when ordering the JS120. The model code begins with the product family name and the remaining fields are filled in to configure the product with the desired features. -
Page 6: Center Tap
Product configuration model code Center tap A center tap (spring return to center option) is a standard JS120 feature, where 50% of the supply voltage can be supplied to force the sensor voltage to this known reference. When the center tap is not connected there will be a center dead band (where the voltage output does not change on initial deflection). -
Page 7: Product Installation
Long lever Short lever JS120 is designed to be fitted down into the panel, through the panel cutout. Panel seal integrity can be achieved by using sealing gasket. Mounting screws can be driven to a recommended torque of 1 N•m (9 lbf•in). -
Page 8: Connector Pin Assignments
Technical Information JS120 Single Axis Fingertip Joystick Product installation Connector pin assignments Connector kwa1447351557847 Pin assignments (connector end view) kwa1391820928784 Pinout and wiring information JS120-0002, 0003, 0005, 0006 JS120-0008, 0009, 0010, 0011 Direction switch common Direction switch common Direction switch +Y (N/O) -
Page 9: Machine Wiring Guidelines
Technical Information JS120 Single Axis Fingertip Joystick Product installation Machine wiring guidelines • Protect wires from mechanical abuse, run wires in flexible metal or plastic conduits. • Use 85˚ C (185˚ F) wire with abrasion resistant insulation and 105˚ C (221˚ F) wire should be considered near hot surfaces. -
Page 10: Joystick Safety Critical Functions
Take steps to detect and manage joystick and system failures that may cause an erroneous output. For safety critical functions Danfoss recommends you use an independent momentary action system enable switch. You can incorporate this switch into the joystick as an operator presence switch or can be a separate foot or hand operated momentary switch. -
Page 11: Product Specifications
Technical Information JS120 Single Axis Fingertip Joystick Product specifications Electrical characteristics Electrical characteristics Potentiometric Sensor type 28° ± 1° Electrical angle of movement center return Start 2° ± 1°, end return full angle 56° ± 1° Electrical angle of movement end return 5 kΩ... -
Page 12: Environmental Parameters
Technical Information JS120 Single Axis Fingertip Joystick Product specifications Environmental parameters Environmental parameters -25°C to 70°C [-13°F to 158°F] Operating temperature -40°C to 85°C [-40°F to 185°F] Storage temperature IP 66 above panel, IP 40 below panel Environmental sealing above the flange... - Page 13 Technical Information JS120 Single Axis Fingertip Joystick 520L0877 | BC00000075en-US0303 | 13 © Danfoss | December 2016...
- Page 14 Technical Information JS120 Single Axis Fingertip Joystick 520L0877 | BC00000075en-US0303 14 | © Danfoss | December 2016...
- Page 15 Technical Information JS120 Single Axis Fingertip Joystick 520L0877 | BC00000075en-US0303 | 15 © Danfoss | December 2016...
- Page 16 Phone: +86 21 3418 5200 Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products already on order provided that such alterations can be made without changes being necessary in specifications already agreed.
