Danfoss JS6000 Technical Information page 42

Technical Information
Specifications
42
JS6000 Joystick Base
Dual potentiometer output
Minimum voltage Maximum voltage
(% Vs) (% Vs)
10 ± 2 90 ± 2
Hall effect sensor with analog output
Supply voltage (Vs)
Maximum survival supply voltage
Maximum current draw (base only) 90 mA
Minimum output voltage
Center voltage
Maximum output voltage
Hall effect sensor with can output option
Supply voltage (Vs)
Maximum current draw (base only) 90 mA
Supports CAN 2.0B with SAE J1939 message protocol
Hall effect sensor with pwm output option
Supply voltage (Vs)
Maximum survival supply voltage
Maximum current draw (base only) 13 amps
Valve outputs
Digital outputs
Maximum output current
External-to-joystick digital inputs
Property Minimum
Allowed voltage at pin 0 Vdc
Rising voltage threshold 2.48 Vdc
Falling voltage threshold 1 Vdc
CAN output latency 6 ms
Response to voltage below
minimum
Response to voltage above
maximum
520L0760 • Rev 1102 • November 2015
Switch track angle Resistance
(°) (kΩ)
± 1.5 1.6 to 2.4
5 ± -0.5 Vdc
18 Vdc
10% ± 4% Vs
50% ± 2% Vs
90% ± 4% Vs
9 to 36 Vdc
9 to 36 Vdc
40 Vdc
2.5 amps maximum
3.0 amps maximum
13.0 amps
Maximum
36 Vdc
3.5 Vdc
2.25 Vdc
24 ms
Model code order
character
U
Comments
Digital input will be read as
high if voltage is greater
than 3.5 Vdc
Digital input will be read as
low if voltage is less than 1
Vdc
Based on update rate of
application software
Non-damaging, non-
latching: reading saturates
to low limit
Non-damaging; non-
latching: reading saturates
to high limit
