vacon • 148
6.2

Option board slots

The parameters of this group depend on the option board installed. If no option board is placed in
slots C, D or E, no parameters are visible. See chapter 8.5.1 Programming of digital and analogue
inputs for the location of the slots.
As an option board is removed, info text 39
Table 133.
Menu
Slot C
Slot D
Slot E
6.3

Real time clock

Table 93. I/O and Hardware menu, Real time clock parameters
Index Parameter
V5.5.1 Battery state
P5.5.2
P5.5.3
P5.5.4
P5.5.5 Daylight saving
6
Table 92. Option board-related parameters
Function
Settings
Monitoring
Settings
Monitoring
Settings
Monitoring
Min Max
1 3
Time
Date
Year
1 4
Device removed
will appear on the display. See
Description
Option board related settings.
Monitor option board-related info.
Option board related settings.
Monitor option board-related info.
Option board related settings.
Monitor option board-related info.
Unit Default ID
2 2205
hh:mm:ss 2201 Current time of day
dd.mm. 2202 Current date
yyyy 2203 Current year
1 2204
Tel. +358 (0) 201 2121 • Fax +358 (0)201 212 205
I/O and hardware menu
Description
Status of battery.
1 = Not installed
2 = Installed
3 = Change battery
Daylight saving rule
1 = Off
2 = EU; Starts on last Sunday
in March, ends last Sunday in
October
3 = US; Start on 2nd Sunday
in March, ends on 1st Sunday
in November
4 = Russia (permanent)
