PRODUCT OVERVIEW

PRODUCT DESCRIPTION

The Tungsten Smart-Heat Series Gas Radiant Heaters are designed to provide effective heating.
The heaters incorporate full function electronic controls, allowing them to be operated remotely from a conveniently located
switch. The heaters have been designed to withstand the rigors of the outdoors.
NOTE: The Tungsten heaters are designed only for wall mounting or ceiling pole mounting
TUNGSTEN SMART-HEAT HEATER DIMENSIONAL DETAILS
Without Heater
Deflector
With Heater
Deflector
IMPORTANT
!
This appliance is approved for outdoor or amply ventilated area use and for NON DOMESTIC INDOOR APPLICATIONS,
and must be installed by authorised persons. For commissioning of the appliance see page 8.
This appliance is to be protected from rain. Install under a protective cover.
This appliance must be installed in accordance with the rules in force. Before installation, check that the local distribution
conditions, nature of gas and pressure, and adjustment of the appliance are compatible.

GENERAL INFORMATION

The Tungsten Series Gas radiant heaters are suitable for outdoor or amply ventilated areas and non domestic indoor use. In
addition to the installation instructions provided, authorised installers must abide by the local gas installation code. Please
note that these standards are subject to change.
The heater is designed to function in winds up to 15Km/h. The heater is subject to reduced performance or failure in adverse
weather conditions such as high wind or extreme saturation.
!
WARNING
• Do not expose the burner to water or moisture. THE APPLIANCE IS TO BE PROTECTED FROM RAIN.
• Do not use the heater if any of these parts are exposed to water until the appliance is inspected or repaired by an
authorized service person.
6
356
135
Wall Bracket / Control Housing
Mounting Hole Positions
497
255
316
150
