TUNGSTEN SMART-HEAT™
PORTABLE HEATER
BY BROMIC
INSTALLATION, INSTRUCTION AND
SERVICE MANUAL
SUITABLE FOR GAS RADIANT HEATER MODELS:
TUNGSTEN SMART-HEAT™
Do not store or use petrol or other amable vapor
and liquids in the vicinity of this or any other
appliance.
An LP-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
the
!
gas
WARNING: Improper installation,
adjustment, alteration, service or maintenance
can cause property damage, injury or death.
Read the installation, operating and
maintenance instructions thoroughly before
installing or servicing this equipment.
If you smell gas:
1.
Shut o gas to the appliance
2.
Extinguish any open ame
3.
If odour continues, keep away from the
appliance and immediately call your gas
supplier or re department.
!
WARNING: For Outdoor Use Only.
Version 1.3 USA / Can
WARNING
!
DANGER
!
WARNING
!
Do not store or use petrol or other amable vapor
and liquids in the vicinity of this or any other
appliance.
An LP-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
!
WARNING: Improper installation,
adjustment, alteration, service or maintenance
can cause property damage, injury or death.
Read the installation, operating and
maintenance instructions thoroughly before
installing or servicing this equipment.

Advertisement

Table of Contents
loading

Summary of Contents for Bromic Heating Tungsten Smart-Heat

  • Page 1 TUNGSTEN SMART-HEAT™ PORTABLE HEATER BY BROMIC INSTALLATION, INSTRUCTION AND SERVICE MANUAL SUITABLE FOR GAS RADIANT HEATER MODELS: TUNGSTEN SMART-HEAT™ WARNING Do not store or use petrol or other amable vapor and liquids in the vicinity of this or any other appliance.
  • Page 2 Note: Bromic Heating Pty Ltd reserves the right to make changes to specifications, parts, components and equipment without prior notification. This Installation, operation and service manual may not be reproduced in any form without prior written consent from Bromic Heating Pty Ltd.
  • Page 3: Table Of Contents

    CONTENTS IMPORTANT NOTES & WARNINGS PRODUCT OVERVIEW PRODUCT DESCRIPTION SPECIFICATIONS GENERAL INFORMATION PRODUCT FEATURES INSTALLATION REQUIREMENTS GAS REQUIREMENTS INSTALLATION CLEARANCES INSTALLATION INSTRUCTIONS 9-20 HEATER INSTALLATION INSTRUCTIONS 9-19 LEAKAGE TEST OPERATING INSTRUCTIONS TURNING THE APPLIANCE ON TURNING THE APPLIANCE OFF MAINTENANCE AND SERVICING TROUBLE SHOOTING APPENDIX A 24 - 26...
  • Page 4: Important Notes & Warnings

    Any guard or other protective device removed for servicing appliance must be used. Replacement regulator and hose (conducted by an authorised person) must be replaced before assemblies must be purchased from Bromic Heating Pty Ltd. operating the heater. • Children and adults should be alerted to the hazards of high •...
  • Page 5: Product Overview

    Injector size 0.85mm Weight 56Kg - 123.5lB Safety features Flame failure device, anti-tilt switch Gas supply pressure Min 11”wc – Max 14”wc TUNGSTEN SMART-HEAT™ HEATER DIMENSIONAL DETAILS 700mm 2.3ft 2160mm 7.1ft 700mm 2.3ft IMPORTANT This appliance is to be protected from rain. Install under a protective cover.
  • Page 6: General Information

    PRODUCT OVERVIEW CONTINUED... GENERAL INFORMATION The TUNGSTEN Gas Patio Heaters are suitable for outdoor spaces. In addition to the installation Instructions provided, authorized installers must abide by local codes, or in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54, Natural Gas and Propane Installation Code, CSA B149.1, or Propane Storage and Handling Code, B149.2.
  • Page 7: Installation Requirements

    INSTALLATION REQUIREMENTS IMPORTANT GAS REQUIREMENTS TUNGSTEN Smart-Heat LPG Model: Installation and repair should be done by a qualified service • Use Propane (LPG) gas cylinder only person. The heater should be inspected before use and at • The approved manifold pressure to the appliance is 10”...
  • Page 8: Installation Clearances

    INSTALLATION REQUIREMENTS CONTINUED... LOCATION CLEARANCES When selecting the location for the TUNGSTEN Gas Patio Heater, the following clearances should be followed. Care should be taken to ensure that the heater is not installed: • Where heat/ignition can cause damage to gas cylinders/lines •...
  • Page 9: Installation Instructions

    INSTALLATION INSTRUCTIONS CONTENTS PACKED IN (2) BOXES CONTENTS PACKED IN (2) BOXES Box 1 Contents Head Assembly AAA Battery Box 2 Contents Base Assembly Front Assembly Rear Arm Assembly x 2 Side Panels x 2 Top Arms x 2 Rear Cover Top Flame De ector Regulator www.bromicheating.com...
  • Page 10 INSTALLATION INSTRUCTIONS CONTINUED... Supplied Fasteners M8 x 95mm M8 x 45mm M8 x 16mm M5 x 8mm G8 x 8mm QTY: 4 QTY: 2 QTY: 2 QTY: 4 QTY: 12 M8 x 20mm QTY: 4 M8 x Washer QTY: 4 Supplied Tools M8 Hex Key Tools Not Included...
  • Page 11 INSTALLATION INSTRUCTIONS CONTINUED... STEP 1: Unpack boxes and place all items on a non abrasive surface. STEP 2: Fasten rear arms to base using 2 x M8 20mm screws and the supplied M8 Hex Key. STEP 3: Position front assembly and fasten using 2 x M8 20mm screws using supplied M8 Hex Key. www.bromicheating.com...
  • Page 12 INSTALLATION INSTRUCTIONS CONTINUED... STEP 4: Secure the rear arms to front assembly using 2 x M8 x 16mm screws and supplied M8 Hex Key. STEP 5: Secure the side panels to frame using 12 x G8 screws - A Phillips screw driver is required for this step. Repeat for opposite side.
  • Page 13 INSTALLATION INSTRUCTIONS CONTINUED... STEP 6: Slide top arms over front assembly slip joints - Ensure top screw holes are faced inwards. Secure the front panel to top arms using 4 x M5 screws and supplied M5 Hex Key. * Note: The joint between the lower and upper arms is rm to ensure` rigidily and stability of the product.
  • Page 14 INSTALLATION INSTRUCTIONS CONTINUED... STEP 8: Lay both heater head and stand on a non abrasive surface as shown. Two people are required for this step. NON ABRASIVE SURFACE STEP 9: Feed gas hose through arm slot and push through until it reaches slot in bottom arm. Keep feeding hose until all slack is taken up.
  • Page 15 INSTALLATION INSTRUCTIONS CONTINUED... INSTALLATION INSTRUCTIONS CONTINUED... STEP 10: Secure the heater head to arms using 4 x M8 screws and supplied washers with M8 Hex Key. CONTINUED... STEP 13: Return heater to upright position. Two people are required for this step. NON ABRASIVE SURFACE www.bromicheating.com...
  • Page 16 INSTALLATION INSTRUCTIONS CONTINUED... STEP 15: STEP 14: Place gas bottle into lower enclosure and fasten Screw regulator assembly strap tightly. to gas bottle. STEP 16: Pull sleeve back on regulator connector, insert hose tting & release sleeve on regulator STEP 17: connector.
  • Page 17 INSTALLATION INSTRUCTIONS CONTINUED... STEP 18: Secure de ector to heater by loosening the two screws and secure brackets underneath washers. Re-tighten screws to original position using screw driver. INSTALLATION INSTRUCTIONS CONTINUED... STEP 19: Unscrew igniter cap. Insert supplied AAA battery into cap and re-scew to original position STEP 20: Perform Gas leakage test as shown on page 20 www.bromicheating.com...
  • Page 18 INSTALLATION INSTRUCTIONS CONTINUED... CONTINUED... STEP 21: The back cover is secured by magnets. Firstly position slots in back cover over the two hooks then lower cover to allow magnets to catch www.bromicheating.com...
  • Page 19 INSTALLATION INSTRUCTIONS CONTINUED... CONTINUED... Adjusting the heater head angle CAUTION: ONLY ADJUST THE HEATER HEAD ANGLE PRIOR TO OPERATION. ADJUSTING WHILST UNIT IS IN OPERATION OR POST OPERATION CAN CAUSE SERIOUS BURNS High Head Tilt Position To set heater head angle at high position, manually push heater head up to align hole then insert slip pin.
  • Page 20: Leakage Test

    INSTALLATION INSTRUCTIONS CONTINUED... LEAK TEST Gas connections on heater are leak tested at the factory prior to shipment. A complete gas leak test must also be performed after assembly before operating the heater due to possible damage occurring during transportation. •...
  • Page 21: Operating Instructions

    OPERATING INSTRUCTIONS WARNING Do not turn the heater on with people standing in front of heater. TURNING THE APPLIANCE ON Heater must be turned on while standing behind the heater. WARNING 1. Ensure that installation has been carried out in accordance Improper lighting procedures can cause personal injury, property with the manufacturers instructions outlined in this document.
  • Page 22: Maintenance And Servicing

    Inspect and clean at least every six months or 10. Replacement parts can be purchased to restore the more frequently in adverse conditions. heater to its original appearance from Bromic Heating Never obstruct the flow of combustion and ventilation Pty Ltd.
  • Page 23: Troubleshooting

    TROUBLESHOOTING What ONLY an What you can do Problem Possible cause authorised service (if these do not work, contact an authorised technician) technician can do Burner will not • Gas valve may be OFF • Turn the gas valve ON •...
  • Page 24: Appendix A

    APPENDIX A www.bromicheating.com...
  • Page 25 APPENDIX A CONTINUED... www.bromicheating.com...
  • Page 26: Appendix A

    APPENDIX A CONTINUED... www.bromicheating.com...
