TUNGSTEN SMART-HEAT™

GAS HEATER

BY BROMIC

INSTALLATION, INSTRUCTION AND

SERVICE MANUAL

SUITABLE FOR GAS RADIANT HEATER MODELS:

TUNGSTEN 300 - BURNER AND TUNGSTEN 500 - BURNER

If you smell gas:

Shut o gas to the appliance

Extinguish any open ame

If odour continues, keep away from the

appliance and immediately call your gas

supplier or re department.

WARNING: For Outdoor Use Only.

This appliance shall not be installed or

used indoors.

Version4.0 EUROPE

DANGER

WARNING

Do not store or use petrol or other amable vapor

and liquids in the vicinity of this or any other

appliance.

An LP-cylinder not connected for use shall not be

stored in the vicinity of this or any other appliance.

WARNING: Improper installation,

adjustment, alteration, service or maintenance

can cause property damage, injury or death.

Read the installation, operating and

maintenance instructions thoroughly before

installing or servicing this equipment.

Table of Contents

Need help?

Do you have a question about the TUNGSTEN 300-BURNER and is the answer not in the manual?

Questions and answers

Summary of Contents for Bromic Heating TUNGSTEN 300-BURNER

Page 1 TUNGSTEN SMART-HEAT™ GAS HEATER BY BROMIC INSTALLATION, INSTRUCTION AND SERVICE MANUAL SUITABLE FOR GAS RADIANT HEATER MODELS: TUNGSTEN 300 - BURNER AND TUNGSTEN 500 - BURNER WARNING DANGER Do not store or use petrol or other amable vapor If you smell gas: and liquids in the vicinity of this or any other appliance.
Page 2 Note: Bromic Heating Pty Ltd reserves the right to make changes to specifications, parts, components and equipment without prior notification. This Installation, operation and service manual may not be reproduced in any form without prior written consent from Bromic Heating Pty Ltd.
Page 3: Table Of Contents
CONTENTS IMPORTANT NOTES & WARNINGS PRODUCT OVERVIEW SPECIFICATIONS PRODUCT DESCRIPTION GENERAL INFORMATION PRODUCT FEATURES INSTALLATION REQUIREMENTS GAS REQUIREMENTS INSTALLATION CLEARANCES INSTALLATION INSTRUCTIONS HEATER INSTALLATION INSTRUCTIONS GAS SUPPLY INSTALLATION POWER SUPPLY INSTALLATION LEAKAGE TEST HEAT DEFLECTOR INSTALLATION INSTRUCTIONS CEILING MOUNT POLE INSTALLATION INSTRUCTIONS OPERATING INSTRUCTIONS TURNING THE APPLIANCE ON TURNING THE APPLIANCE OFF...
Page 4: Important Notes & Warnings
IMPORTANT NOTES AND WARNINGS • Do not use the heater until all connections have been WARNING leak tested by an authorized person. • Inspect the hose assembly before each use of the • THIS APPLIANCE SHALL NOT BE INSTALLED OR USED appliance.
Page 5: Product Overview
PRODUCT OVERVIEW SPECIFICATIONS ( Table 1 ) Tungsten Smart-Heat 300 Gas type G31 PROPANE G20 NATURAL GAS G30 BUTANE G20 NATURAL GAS G25 NATURAL GAS Gas Category (30) (37) (50) (20) (20) (25) (20/25) (30) (50) 3B/P 3B/P Injector Size 0.82 0.82 0.82...
Page 6: Product Description
PRODUCT OVERVIEW PRODUCT DESCRIPTION The Tungsten Smart-Heat Series Gas Radiant Heaters are designed to provide effective heating. The heaters incorporate full function electronic controls, allowing them to be operated remotely from a conveniently located switch. The heaters have been designed to withstand the rigors of the outdoors. NOTE: The Tungsten heaters are designed only for wall mounting or ceiling pole mounting TUNGSTEN SMART-HEAT HEATER DIMENSIONAL DETAILS Without Heater...
Page 7: Installation Requirements
FOR INSTALLATION AND USE IN OUTDOOR OR AMPLY VENTILATED AREAS GAS REQUIREMENTS • An amply ventilated area must have a minimum of 25% of the surface area open. Tungsten Smart-Heat LPG Models: • The surface area is the sum of the walls surface •...
Page 8: Installation Clearances
INSTALLATION REQUIREMENTS CONTINUED... INSTALLATION CLEARANCES The stated clearance to combustible materials represents surface temperature of 65 C above room temperature. Building material When selecting the installation location for the Tungsten with a low heat tolerance (such as plastic, vinyl siding, canvas, tri- Smart-Heat Gas Heaters, the following mounting clearances ply etc.) may subject to degradation at lower temperature.
Page 9: Installation Instructions
INSTALLATION INSTRUCTIONS HEATER INSTALLATION INSTRUCTIONS Connect approved Flexible Connector supplied) to the inlet fitting on the heater using 2 WARNING wrenches to tighten. Leak Test by applying compressed air 60mbar to open end of flexible hose. Spray gas This appliance must be installed and used in accordance fittings with a soapy water solution and Check for leaks.
Page 10 INSTALLATION INSTRUCTIONS CONTINUED... Attach Heater to Wall Bracket/Control Housing Connect an approved flexible connector to the Gas Valve Outlet Fitting • Remove Front Cover from Control Housing • Position heater and hose so that the gas hose and • Attach Heater to Wall Bracket/Control Housing fitting are in alignment by inserting Mounting Arm into lower channel of Wall Bracket.
Page 11 INSTALLATION INSTRUCTIONS CONTINUED... For Honeywell Control Insert Pivot Bolt • Position Arm so that the rear hole’s on the mounting • Using a pair of needle nose pliers, grip the white arm and Control Housing are in alignment ionisation terminal as shown, being mindful of the •...
Page 12 INSTALLATION INSTRUCTIONS CONTINUED... Connect gas inlet fitting to mains gas supply in accordance 10. Main Power supply connection is to completed in line with local gas installation code and gas supply installation with instructions in the “Power supply installation” section of manual. Leak test with soapy water. section of this manual.
Page 13: Gas Supply Installation
INSTALLATION INSTRUCTIONS CONTINUED... GAS SUPPLY INSTALLATION POWER SUPPLY INSTALLATION Before installing, check that the local distribution conditions, WARNING nature of gas and pressure and adjustment of the appliance are compatible. Where multiple appliances are installed and supplied This heater is equipped with a three-prong (grounding) from a common gas supply it is important to check that the gas plug for your protection against shock hazard and should supply pipe is adequately sized for the number of appliances fitted.
Page 14: Heat Deflector Installation Instructions
INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS CONTINUED... CONTINUED... LEAKAGE TEST - CONTINUED COMMISSIONING INSTRUCTION (CARRY OUT LEAKAGE TEST IF NOT ALREADY DONE) CHECK GAS PRESSURE WARNING IMPROPER INSTALLATION AND ALTERATION CAN CAUSE INJURY AND PROPERTY DAMAGES. READ THE INSTALLATION AND OPERATING MANUAL THOROUGHLY BEFORE INSTALLING THE HEATER.
Page 15 CEILING POLE INSTALLATION Mount Top Bracket to ceiling or support beam using suitable fixings no less than 60mm length. WARNING When mounting ceiling pole, ensure the anchoring to the structure is of sufficient strength, quality and workmanship to support the weight of the heater and any other load that could be applied to the fixture.
Page 16: Operating Instructions
OPERATING INSTRUCTIONS TURNING THE APPLIANCE ON NOTE: The appliance must be completly shutoff for a period of 5 minutes before being relighted. Ensure that gas installation and power installation has IMPORTANT been carried out in accordance with the manufacturers instructions outlined in this document. Check the heater immediately if any of the following occurs: Turn on gas supply.
Page 17: Optimum Mounting Distance
IMPORTANT Replacement parts can be purchased to restore the heater to its original appearance from Tungsten Heating Pty Ltd. (Refer Do not apply any additional surface coating to the heater under any to parts list in manual). circumstances. Use of additional coating other than those applied during manufacture could result in hazardous reactions such as toxic fumes or fires.
Page 18: Honeywell Valve
OPERATION DATA - HONEYWELL CONTROL BOX CONTINUED... Directions for use Operation • Automatic controls are safety devices and shall not be At every start, the control unit proceeds to a self-checking opened. The manufacturer’s responsibility and guarantee of its own components. During the pre-purge or waiting are invalid if the control is unduly opened.
Page 19: Wiring Diagram
WIRING DIAGRAM - HONEYWELL CONTROL, HONEYWELL GAS VALVE ELECTRICAL DIAGRAM SEE INSTRUCTION MANUAL FOR DETAILS ON HOW TO CONNECT THE ELECTRICAL COMPONENTS. Ionisation Ionisation Ignition + Brown 230 V Blue Red 230 V HONEYWELL White Black Yellow/Green Note: If any of the original wire as supplied with the heater must be replaced, it must be replaced with 18AWG, 90ºC type UL approved wire or its equivalent.
Page 20: Replacement Parts
REPLACEMENT PARTS Honeywell bromic.com/heat...
Page 21 Heater Replacement Screw Set Note: For more information on obtaining spare parts contact the place of purchase or BROMIC HEATING Head O ce : 10 Phiney Place, Ingleburn NSW 2565 Australia Telephone: 1300 276 642 (within Australia) or +61 2 9748 3900 (from overseas) Fax: +61 2 9748 4289 Email: info@bromic.com Web: www.bromiccom/heat...
Page 22: Post-Installation Report
FOR TUNGSTEN SMART-HEAT GAS RADIANT HEATERS AFTER HEATER INSTALLATION PLEASE PHOTOCOPY, COMPLETE, & SEND THIS REPORT BY: FAX TO (02) 9748 4289 or BY MAIL TO Bromic Heating Pty Ltd, 1 Suttor Street, Silverwater NSW 2128 Australia or SCAN AND EMAIL TO info@bromicheating.com...
Page 23: Troubleshooting
TROUBLESHOOTING SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION Heater will not turn on No power Have authorized electrician check No gas power supply Control module in Lock-out mode Have authorized gas fitter check gas supply See page 17. Reset Honeywell Lock-out Heater turns on, but then cycles on Insufficient flame on ionisation rod and off Drafty conditions...
Page 24 APPENDIX A Note: For clearance from combustible materials see page 7 bromic.com/heat...
Page 25 APPENDIX A CONTINUED... bromic.com/heat...
Page 26 APPENDIX A CONTINUED... Abbreviation Country AUSTRIA BELGIUM BULGARIA SWITZERLAND CYPRUS CZECH REPUBLIC GERMANY DENMARK ESTONIA SPAIN FINLAND FRANCE GREAT BRITAIN GREECE CROATIA HUNGARY IRELAND ICELAND ITALY LITHUANIA LUXEMBOURG LATVIA MALTA NETHERLANDS NORWAY POLAND PORTUGAL ROMANIA SWEDEN SLOVENIA SLOVAKIA TURKEY bromic.com/heat...
