tungsten smart-heat™
electric heater
BY BrOmic
INsTAllATION, INsTRucTION ANd
seRvIce MANuAl
SUITABLE FOR ELECTRIC HEATER MODELS:
TUNgSTEN 2000W, 3000W, 4000W- AND TUNgSTEN 6000W
IMPORTANT
!
READ THIS MANUAL CAREFULLY.
SEE INSIDE COVER FOR IMPORTANT
INFORMATION ABOUT THIS MANUAL.KEEP
INSTRUCTION WITH APPLIANCE FOR FUTURE
REFERENCE.
Version 1.4 USA
Advertisement
Table of Contents
Related Manuals for Bromic Heating Tungsten 2000w
Summary of Contents for Bromic Heating Tungsten 2000w
- Page 1 BY BrOmic INsTAllATION, INsTRucTION ANd seRvIce MANuAl SUITABLE FOR ELECTRIC HEATER MODELS: TUNgSTEN 2000W, 3000W, 4000W- AND TUNgSTEN 6000W IMPORTANT READ THIS MANUAL CAREFULLY. SEE INSIDE COVER FOR IMPORTANT INFORMATION ABOUT THIS MANUAL.KEEP INSTRUCTION WITH APPLIANCE FOR FUTURE REFERENCE.
- Page 2 Email: info@bromicheating.com Web: www.bromicheating.com Note: Bromic Heating reserves the right to make changes to specifications, parts, components and equipment without prior notification. This Installation, operation and service manual may not be reproduced in any form with prior written consent from Bromic Heating. www.bromicheating.com...
-
Page 3: Table Of Contents
CONTENTS IMPORTANT NOTES & WARNINGS PRODUCT OVERVIEW PRODUCT DESCRIPTION AND fEATURES SPECIfICATIONS HEATER INSTALLATION INSTALLATION CLEARANCES CEILING WALL MOUNTING CHAIN SUSPENSION ELEMENT INSTALLATION ELECTRICAL INSTALLATION WIRING DIAGRAMS SERVICING MAINTENANCE TUbE ELEMENT REPLACEMENT REPLACEMENT PART LIST TROUbLESHOOTING www.bromicheating.com... -
Page 4: Important Notes & Warnings
IMPORTANT NOTES AND WARNINgS INSTALLATION WARNING • IMPORTANT - Installation must be carried out by a licensed and authorised person. • Read all instructions before installing or using this heater • The installer is to ensure that the requirements of the local •... -
Page 5: Product Overview
High Temperature Coating *Heating areas are based on protected environment with mounting height of 96” (8’). for unprotected and extremely cold and windy environments heating areas can be less. Please contact bromic Heating for further advice. PROducT FeATuRes • The Tungsten Smart-Heat Electric heaters are • IPX4 water ingress protection rating. -
Page 6: Heater Installation
HEATER INSTALLATION WARNINg WARNINg DO NOT MOUNT THE HEATER VERTICALLY! DO NOT MOUNT THE HEATER VERTICALLY! Heater MUST be installed so that the tube elements For outdoor installation heater must be mounted with are horizontal. Failure to do this will cause the heating face of heater angled down. -
Page 7: Ceiling Wall Mounting
HEATER INSTALLATION CONTINUED... ceIlING & WAll MOuNTING CEILING & WALL MOUNTING Mounting Hole Centres & Heater Position 2000W & 4000 Models (1) Mark mounting hole centres on ceiling or wall. 1. Mark mounting hole centres on ceiling or wall. 24” 3000W &... -
Page 8: Element Installation
ELEMENT INSTALLATION WARNINg This Heater MUST be permanently Installed and hard wired by an authorised/licenced person. Do Not perform maintenance, or carry out installation or assembly procedure while electrical power is switched on. 1. Remove the front cover from the heater. 2. - Page 9 ELEMENT INSTALLATION CONTINUED... 5. Close element lock bracket & fasten with self tapping screw. Repeat for other end of heater. 6. Assemble end caps at both ends of the heater with 2 self tapping screws. for 4000W & 6000W models ensure that the middle tab of the end caps are slotted behind the element support bracket.
-
Page 10: Electrical Installation
ELECTRICAL INSTALLATION WARNINg has the two marked and two unmarked pig tails. Use the two marked pig tails for the first element. Use the This Heater MUST be permanently Installed and hard two unmarked pig tails for the second elements. Earth wired by an authorised/licenced person. -
Page 11: Wiring Diagrams
TUNGSTEN SMART HEATER ELECTRIC WIRING DIAGRAM 2000 WATTS and 3000 WATTS 240 V AC Heater Junction Single Phase Element 1 Earth Wire CONNECT TO WARNING 240 V AC Single phase CHASSIS junction box wirings must be permanently installed by an authorised licenced person www.bromicheating.com... - Page 12 TUNGSTEN SMART HEATER ELECTRIC WIRING DIAGRAM 4000 WATTS and 6000 WATTS 240 V AC Heater Heater Junction Single Phase Element 1 Element 2 Earth Wire WARNING 240 V AC Single phase junction box wirings must be permanently installed CONNECT TO by an authorised licenced person CHASSIS www.bromicheating.com...
-
Page 13: Servicing
SERVICINg WARNING 5. Remove Outer Hex Nut, Lock Washer and Lead Wire Ring Terminal from the threaded stud. Servicing and maintenance MUST be carried out by an 6. Remove old Tube Element. authorised and licensed person only 7. Install new Tube Element by following element installa- tion instructions on page 8 of this manual. -
Page 14: Replacement Part List
REPLACEMENT PART LIST Description BH0420002 BH0420003 BH0420004 BH0420005 (2000W) (3000W) (4000W) (6000W) Tube Element bH8180001 bH8180002 bH8180001 bH8180002 front Cover bH8180003 bH8180004 bH8180003 bH8180004 Element End Cover Set bH8180005 bH8180006 bH8180005 bH8180006 Junction box Cover & Seal Set bH8180007 bH8180007 bH8180007 bH8180007 Mounting bracket Set (Short)
