PLATINUM SMART-HEAT™
GAS HEATER
BY BROMIC
INSTALLATION, INSTRUCTION AND
SERVICE MANUAL
SUITABLE FOR GAS RADIANT HEATER MODELS:
PLATINUM 300 - BURNER AND PLATINUM 500 - BURNER
!
If you smell gas:
1.
Shut o gas to the appliance
2.
Extinguish any open ame
3.
If odor continues, keep away from the
appliance and immediately call your gas
supplier or re department.
WARNING: For Outdoors Use Only.
!
ENGLISH VERSION FROM PAGES 1 - 27
DANGER
WARNING
!
Do not store or use gasoline or other amable
vapor and liquids in the vicinity of this or any
other appliance.
An LP-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
!
WARNING: Improper installation,
adjustment, alteration, service or maintenance
can cause property damage, injury or death.
Read the installation, operating and
maintenance instructions thoroughly before
installing or servicing this equipment.
Advertisement
Table of Contents
Related Manuals for Bromic Heating PLATINUM SMART-HEAT
Summary of Contents for Bromic Heating PLATINUM SMART-HEAT
- Page 1 PLATINUM SMART-HEAT™ GAS HEATER BY BROMIC INSTALLATION, INSTRUCTION AND SERVICE MANUAL SUITABLE FOR GAS RADIANT HEATER MODELS: PLATINUM 300 - BURNER AND PLATINUM 500 - BURNER WARNING DANGER Do not store or use gasoline or other amable If you smell gas: vapor and liquids in the vicinity of this or any other appliance.
- Page 2 IMPORTANT This manual contains important information about the assembly, operation, and maintenance of Platinum Smart-Heat Series Heaters. Please pay close attention to the important safety information shown throughout this instruction manual. Any safety information will be accompanied by the following safety alert symbols:...
-
Page 3: Table Of Contents
CONTENTS IMPORTANT NOTES & WARNINGS PRODUCT OVERVIEW PRODUCT DESCRIPTION SPECIFICATIONS GENERAL INFORMATION PRODUCT FEATURES INSTALLATION REQUIREMENTS GAS REQUIREMENTS INSTALLATION CLEARANCES INSTALLATION INSTRUCTIONS HEATER INSTALLATION INSTRUCTIONS GAS SUPPLY INSTALLATION POWER SUPPLY INSTALLATION LEAKAGE TEST HEAT DEFLECTOR INSTALLATION INSTRUCTIONS CEILING MOUNT POLE INSTALLATION INSTRUCTIONS OPERATING INSTRUCTIONS TURNING THE APPLIANCE ON TURNING THE APPLIANCE OFF... -
Page 4: Important Notes & Warnings
IMPORTANT NOTES AND WARNINGS Do not use the heater until all connections have been WARNING leak tested by an authorized person. Inspect the hose assembly before each use of the THIS APPLIANCE SHALL NOT BE INSTALLED OR USED appliance. IN RESIDENTIAL DOMESTIC INDOOR AREAS The hose assembly must be replaced prior to the CHILDREN AND ADULTS SHOULD BE ALERTED TO THE appliance being put into operation if there is evidence of... -
Page 5: Product Overview
PRODUCT OVERVIEW PRODUCT DESCRIPTION The Platinum Smart-Heat Gas Radiant Heaters are designed to provide effective outdoor heating to both commercial and residential premises whilst offering an appealing design. The heaters incorporate full function electronic controls, allowing them to be operated remotely from a conveniently located switch. -
Page 6: General Information
PRODUCT FEATURES Platinum Smart-Heat gas radiant heaters are revolutionizing the outdoor heating industry by introducing groundbreaking benefits never seen before in traditional gas or electric heaters. Platinum Smart-Heat heaters have set the industry benchmark with stylish good looks and world-first innovation. -
Page 7: Installation Clearances
In open locations subject to rain In indoor residential locations In areas without sufficient clearances (refer below) Note: When installing with the Platinum Smart-Heat Heat Shield (Part No. 2620165 or 2620166) the following Note: When Installing with No protective cover, the following... -
Page 8: Installation Instructions
Installation should be done by a quali ed service person. CAUTION Please see specifications for the weight of the Heater. The installer of the Platinum Smart-Heat Radiant Heaters must comply with all relevant State Occupational Health & Safety Regulations. Step 1. Mount Wall Bracket/Control Housing To Wall:... - Page 9 INSTALLATION INSTRUCTIONS CONTINUED... Step 4. Attach Heater to Wall Bracket/Control Housing Step 5. Connect the CSA approved flexible connector to the Gas Valve Outlet Fitting Remove Front Cover from Control Housing Position heater and hose so that the gas hose and Attach Heater to Wall Bracket/Control Housing fitting are in alignment by inserting Mounting Arm into lower channel of...
- Page 10 INSTALLATION INSTRUCTIONS CONTINUED... For Honeywell Control 6. Insert Pivot Bolt Position Arm so that the rear hole’s on the mounting Using a pair of needle nose pliers, grip the white arm and Control Housing are in alignment ionisation terminal as shown, being mindful of the Insert Bolt and washer (as supplied) through Control terminal pins of the control module.
- Page 11 INSTALLATION INSTRUCTIONS CONTINUED... 8. Connect gas inlet fitting to mains gas supply in For Fenwal Control accordance with local gas installation code and Feed wiring harness (3 wires) through opening gas supply installation section of manual. Leak test under Fenwal controller so that wires are positioned with soapy water.
-
Page 12: Gas Supply Installation
All Piping Joints should be tested for leaks with a this plug. soapy water solution before use. The Platinum Smart-Heat Heater comes standard with 36” of Gas hose must be located out of pathway where power cord in addition to the Approved 3 pin power plug. -
Page 13: Heat Deflector Installation Instructions
INSTALLATION INSTRUCTIONS CONTINUED... 4. Fix Heater to Lower paddles using suitable fixtures. NOTE: Platinum Heating recommends running power and gas lines, to the heater, inside the pole to reduce visibility and likelihood of damage. HEAT-DEFLECTOR INSTALLATION 1. Remove Heat Deflector and brackets from packaging 2. -
Page 14: Operating Instructions
5 attempts, consult the use. Smoke and odour from the burning of oils used in troubleshooting section of this manual, or contact Bromic manufacturing will appear. Both the smoke and odour will Heating Pty. Ltd for service information. -
Page 15: Optimum Mounting Distance
IMPORTANT its original appearance from Bromic Heating Pty Ltd. (Refer to parts list in manual). Do not apply any additional surface coating to the heater under any circumstances. Use of additional coating other than those applied during manufacture could result in hazardous reactions such as toxic fumes or fires. -
Page 16: Honeywell Valve
OPERATION DATA - HONEYWELL CONTROL BOX CONTINUED... Directions for use Operation Automatic controls are safety devices and shall not be At every start, the control unit proceeds to a self-checking opened. The manufacturer’s responsibility and guarantee of its own components. During the pre-purge or waiting are invalid if the control is unduly opened. -
Page 17: Operation Data - Fenwal Control Box
The Fenwals configuration in the Platinum Smart-Heat series main valve is de-energized immediately. heaters limits it to volatile lockout, i.e. the restart from this Should the main burner fail to light, or flame is not detected... -
Page 18: Dungs Gas Valve
OPERATION DATA - DUNGS GAS VALVE The Dungs GB Valve is a multifunctional Gas Control with TECHNICAL DATA combined regulator and safety shutoff valves. Opening Time Fast Opening <1sec The pressure regulator includes a servo regulator to regulate Slow Opening <10 sec pressure fluctuations in the mains supply. -
Page 19: Wiring Diagram
WIRING DIAGRAM - HONEYWELL CONTROL, HONEYWELL GAS VALVE SEE INSTRUCTION MANUAL FOR DETAILS ON HOW TO CONNECT THE ELECTRICAL COMPONENTS. Ionisation Ignition + Black 110 V Red 230 V Blue White HONEYWELL White Black Yellow/Green Note: If any of the original wire as supplied with the heater must be replaced, it must be replaced with 18AWG, 90ºC type UL approved wire or its equivalent. - Page 20 WIRING DIAGRAM - FENWAL CONTROL, WHITE RODGERS GAS VALVE SEE INSTRUCTION MANUAL FOR DETAILS ON HOW TO CONNECT THE ELECTRICAL COMPONENTS. Green White Blue Black - 110 V 24 V Orange Ignition + Ionisation Yellow/Green Yellow/Green GND. White S 1. Black HT Cable Note: If any of the original wire as supplied with the heater must be replaced, it must be replaced with 18AWG, 90ºC type UL...
- Page 21 WIRING DIAGRAM - FENWAL CONTROL, DUNGS GAS VALVE SEE INSTRUCTION MANUAL FOR DETAILS ON HOW TO CONNECT THE ELECTRICAL COMPONENTS. Green White Blue Black - 110 V 24 V Orange Ignition + Ionisation Yellow/Green Yellow/Green GND. White S 1. Black HT Cable Note: If any of the original wire as supplied with the heater must be replaced, it must be replaced with 18AWG, 90ºC type UL approved wire or its equivalent.
-
Page 22: Replacement Parts
REPLACEMENT PARTS... - Page 23 Transformer – 110V-24V (Fenwal) Note: For more information on obtaining spare parts contact the place of purchase or BROMIC HEATING Head Office: 1 Suttor Street, Silverwater, Sydney, NSW 2128 Australia Telephone: 1300 276 642 (within Australia) or +61 2 9748 3900 (from overseas) Fax: +61 2 9748 4289...
-
Page 24: Post-Installation Report
AFTER HEATER INSTALLATION PLEASE PHOTOCOPY, COMPLETE, & SEND THIS REPORT BY: FAX TO (02) 9748 4289 or BY MAIL TO Bromic Heating Pty Ltd, Suite 1305, 13223 Black Mountain Road San Diego, California 92129 USA or SCAN AND EMAIL TO info@bromicheating.com Customer Business Name: Please fill in the relevant information or circle the... -
Page 25: Troubleshooting
TROUBLESHOOTING SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION Heater will not turn on 1. No power 1. Have authorized electrician check 2. No gas power supply 2. Have authorized gas fitter check gas supply Heater turns on, but then cycles on 1. Insufficient flame on ionisation rod and off 2. - Page 26 APPENDIX A...
- Page 27 APPENDIX A CONTINUED...
