Summary of Contents for Bromic Heating TUNGSTEN SMART-HEAT
Page 1
TUNGSTEN SMART-HEAT™ ELECTRIC WIRELESS DIMMER CONTROL BY BROMIC USER MANUAL IMPORTANT READ THIS MANUAL CAREFULLY. SEE INSIDE COVER FOR IMPORTANT INFORMATION ABOUT THIS MANUAL. KEEP INSTRUCTION WITH APPLIANCE FOR FUTURE REFERENCE. Version 2.1 AU...
Page 2
IMPORTANT This manual contains important information about the installation and operation of Tungsten Electric controller. Please pay close attention to the important safety information shown throughout this instruction manual. Any safety information will be accompanied by the following safety alert symbols: DANGER, WARNING, IMPORTANT...
IMPORTANT NOTES AND WARNINGS • This appliance must only be used on a 240 VAC Single WARNING Phase electricity supply. • Read all instructions before installing or using this heater • This controller is NOT intended to be installed on recreational vehicles and/or boats.
PRODUCT OVERVIEW 1 DESCRIPTION The Wireless Dimmer is suitable for resistive and infrared heaters. The controller allows the power output of the heater to be dimmed down for maximum comfort. The control can be used with 240VAC supply voltages. 1.1 FEATURES Controls ONE 6800W / 4000W heater at 277/240VAC (3080W at 110VAC) or Controls TWO 3400W / 3000W / 2000W heaters Controls up to a maximum of 6000W over the two outputs at 240VAC or Controls ONE 4000W heaters at 240 VAC.
OPERATION 2.2.2 Programming of 7-channel remote Press P1 once and hold down. A continuous beep will sound. While holding the P1 button (during the continuous beep), press a push button on the 7-channel remote that is going to be programmed. The programming is confirmed by an intermittent sound. 100% DIM + All buttons are automatically...
TECHNICAL SPECIFICATION Power Supply 240VAC 50Hz (28.5A. max) Max Output Power 6000W @ 240VAC (28.5A.) Fuse Protection 32A (FWC high speed) Reception Frequency 916MHz Operating Temperature Range -20/+30°C Dimensions 195 x 200 x 75mm Protection Class IP54 Manufactured by Teleco Automation s.r.l. - Italy - www.telecoautomation.com bromic.com/heat The manufacturer reserves the right to modify design features and technical data without notice.
WIRING DIAGRAM ERROR Do not operate in the high voltage area of the electronic board, when it is supplied. SWITCH P1 P2 P3 AREA POWER SUPPLY (LIVE) POWER SUPPLY (NEUTRAL) POWER SUPPLY (GROUND) GROUND (OUTPUT ELEMENT 1) GROUND (OUTPUT ELEMENT 2) OUTPUT ELEMENT 1 (NEUTRAL) OUTPUT ELEMENT 2 (NEUTRAL) OUTPUT ELEMENT 2 (LIVE)
