KYMCO Grand Dink 250 Service Manual page 129

12
. COOLING SYSTEM
Inspect the radiator soldered joints and
seams for leaks.
Blow dirt out from between core fins with
compressed air. If insects, etc., are clogging
the radiator, wash them off.
Carefully straighten any bent fins.
RADIATOR REMOVAL
Drain the coolant. ( 3-9)
Disconnect the air vent tube from the
radiator filler.
Remove the overflow tube clamp and
disconnect the overflow tube.
Loosen the hose band and disconnect the
upper hose and lower hose from the
radiator.
12-5
GRAND DINK 250
Overflow Tube
Air Vent Tube
Upper Hose
Lower Hose
