Tv Programming Instructions - Matrix T7X-01 Service Manual

CHaPTer 10: Treadmill SPeCifiCaTioNS aNd aSSembly GUide

10.6 TV ProGrammiNG iNSTrUCTioNS

1) Press ENTER, 1, 0, 0, 1, ENTER on the number keypad on the upper display and Manager Mode will appear on the display.
2) Press the key next to TV (Figure A), and then press the key next to CHANNEL SCAN.
3) Press the key next to START (Figure B).
4) Press the - key on the number keypad and a Menu will appear on the TV (Figure C).
5) Use the volume keys to move horizontally in the Menu and the channel keys to move up or down. NOTE: You must press buttons quickly in
the Menu or it will minimize within 5 seconds.
6) Move the cursor over to Channel on the top right of the Menu (Figure D), and go down to CHANNEL SCAN, use the volume button to select
it (Figure E).
7) Move the cursor down to START TO SCAN and use the volume button to select it (Figure F).
8) If the channels are now coming in clearly, press the BACK key to return to normal operation (Figure G).
9) If the channels still are not coming in, or are showing in black and white, return to CHANNEL SCAN, and then change the CABLE SYSTEM
to match your incoming cable frequency (Figure H). Reselect START TO SCAN once this has been changed.
10) If the channels are still not coming in clearly, refer to the TV Troubleshooting in Section 8.7.2.
fiGUre a
fiGUre b
fiGUre C fiGUre d
87
