8.11.1 eNTerTaiNmeNT TroUbleSHooTiNG - oVerVieW

fiGUre a
fiGUre b
fiGUre d
50
CHaPTer 8: TroUbleSHooTiNG
1) This section will help with diagnosing problems with TV and
entertainment related equipment that is produced by Matrix
Fitness.
2) Verify that your TV is Matrix brand equipment. Compare your
TV to the TVs in Figures A and B. Compare your controller to
Figure C. If your equipment looks different contact Matrix or the
manufacturer of your TV equipment if known.
3) Verify how your TV is mounted, compare your machine to Figure
D which shows a TV directly mounted to the Treadmill. Figure
E shows a TV mounted using a TV stand separate from the
machine.
4) For Matrix produced and mounted equipment you can use the
information outlined in this section to help with any connection
and power issues you may have. If you have questions that are
specifictotheTValone(settings,programming,menuoptions,
etc) please see the entertainment owner's manual.
fiGUre C
fiGUre e
