  • Page 1 T7xi T7xe TREADMILL OWNER’S MANUAL MX_13_T5x_T7xe_T7xi_OM_Rev1_9.indd 1 3/27/13 10:22 AM...

  • Page 2: Important Precautions

    IMPORTANT PRECAUTIONS IMPORTANT PRECAUTIONS TREADMILL ASSEMBLY LOCATION & SETUP SAVE THESE INSTRUCTIONS TROUBLESHOOTING & MAINTENANCE TREADMILL OPERATION When using a treadmill, basic precautions should always be followed, including the following: Read all instructions before TREADMILL WORKOUTS using this treadmill. It is the responsibility of the owner to ensure that all users of this treadmill are adequately informed of all warnings and precautions.
  • Page 3 DANGER WARNING • Children over the age of 13 or disabled persons should not use the treadmill without adult supervision. TO REDUCE THE RISK OF ELECTRICAL SHOCK: • Use the treadmill only for its intended use as described in the treadmill guide and owner’s manual. Always unplug the treadmill from the electrical outlet immediately after using, before cleaning, performing maintenance and •...

  • Page 4: Electrical Requirements

    110 NEMA 5-20R 110 NEMA 5-20P North American power cord plugs shown. All Matrix 5x, 7xe and 7xi 110 V treadmills require the use of a 100-125 V, 60 Hz and RECEPTACLE PLUG Depending on your country, the plug type may vary.

  • Page 5: Treadmill Assembly

    • Electrical supply may fluctuate in your area. To ensure stable performance of the product, use the proper gauge CONSOLE SERIAL NUMBER: wire. MODEL NAME: MATRIX » Use the information above for initial setup and when calling for service. MX_13_T5x_T7xe_T7xi_OM_Rev1_9.indd 8-9 3/27/13 10:22 AM...

  • Page 6: Required Tools

    Review the contents of the hardware 14 0000086571 Flat Washer 8.2 x 16 x 2.0T Black package for completeness. Contact Matrix Customer Service at 1(866) 693-4863 to 20 0000084935 Left Connection Bracket SPHC 4.0T 5 mm Allen Wrench report any missing items.
  • Page 7 ASSEMBLY STEP 1 ASSEMBLY STEP 2 Remove the MOTOR COVER and set aside.The Open BLACK HARDWARE BAG BLACK HARDWARE BAG CONTENTS : MOTOR COVER need to be removed to gain Assemble both the LEFT AND RIGHT access to the motor compartment so that the wire to the CONSOLE MASTS TREADMILL BASE...
  • Page 8 ASSEMBLY STEP 3 ASSEMBLY STEP 4 Open WHITE HARDWARE BAG. Open BLUE HARDWARE BAG. WHITE HARDWARE BAG CONTENTS : BLUE HARDWARE BAG CONTENTS : Assemble the LEFT AND RIGHT Slide the URETHANE ARMS over the steel SOCKET HEAD CAP SCREW SPACER SOCKET HEAD CAP SCREW FLAT WASHER...
  • Page 9 ASSEMBLY STEP 5 ASSEMBLY STEP 6 Open RED HARDWARE BAG. Open YELLOW HARDWARE BAG. RED HARDWARE BAG CONTENTS : YELLOW HARDWARE BAG CONTENTS : Assemble the CONSOLE BASE to the Make appropriate wire connections to the SOCKET HEAD CAP SCREW RIBBED LOCK WASHER BUTTON SOCKET HEAD CAP SCREW FLAT WASHER...

  • Page 10: Location & Setup

    ASSEMBLY STEP 7 LOCATION & SETUP Replace the MOTOR COVER. T7xe Shown ASSEMBLY COMPLETE! MX_13_T5x_T7xe_T7xi_OM_Rev1_9.indd 18-19 3/27/13 10:22 AM...

  • Page 11: Location Of The Treadmill

    LOCATION OF THE TREADMILL LEVELING THE TREADMILL Place the treadmill on a level and stable surface away from direct 12” Use of shim or adding leveling foot. sunlight. The intense UV light can cause discoloration on the plastics. Locate your treadmill in an area with cool temperatures and low NOTE: It is extremely important that the levelers are correctly adjusted humidity.

  • Page 12: Tensioning The Running Belt

    TENSIONING THE RUNNING BELT After placing the treadmill in the position it will be used, the belt must be checked for proper tension and centering. The belt might need to be adjusted after the first two hours of use. Temperature, humidity, and use cause the belt to stretch at different rates.

  • Page 13: Troubleshooting And Maintenance

    TROUBLESHOOTING & MAINTENANCE T7XE T7XI MX_13_T5x_T7xe_T7xi_OM_Rev1_9.indd 24-25 3/27/13 10:22 AM...
  • Page 14 If these two items are broken parts. Use only replacement parts supplied by Matrix Clean with soap and water cleaners only. Never use solvents not properly maintained they can cause damage to other Fitness Systems.

  • Page 15: Treadmill Operation

    The site provides information including serial numbers, time/distance totals, software versions, and a history of any error codes that the unit has shown. The system will send email notifications for any error messages that occur on the equipment, notifying both Matrix Fitness customer support and the facility.
  • Page 16 USING THE HEART RATE FUNCTION CAUTION – RISK OF INJURY TO PERSONS Your unit is equipped with heart rate pulse grips. While you are preparing to use the treadmill, do not stand on the belt. Place your feet on the side rails before starting the The heart rate function on this product is not a medical device.

  • Page 17: T5X Console Description

    T5X CONSOLE DESCRIPTION The Matrix machine is inspected before it is packaged. It is shipped in two pieces: the base and the console. Carefully unpack the unit and dispose of the box material. Note: There is a thin protective sheet of clear plastic on the overlay of the console that should be removed before use.
  • Page 18 T7XE CONSOLE DESCRIPTION The Matrix machine is inspected before it is packaged. It is shipped in two pieces: the base and the console. Carefully unpack the unit and dispose of the box material. Note: There is a thin protective sheet of clear plastic on the overlay of the console that should be removed before use.
  • Page 19 T7XI CONSOLE DESCRIPTION The Matrix machine is inspected before it is packaged. It is shipped in two pieces: the base and the console. Carefully unpack the unit and dispose of the box material. Note: There is a thin protective sheet of clear plastic on the overlay of the console that should be removed before use.

  • Page 20: Welcome Screen

    WELCOME SCREEN: 7XI CONSOLE OPERATION HOMESCREEN: GETTING STARTED D) GO SCREEN (PREVIOUS PAGE) A) SELECT A USER • Touch the WORKOUT PROGRAM of your choice and follow the on-screen prompts or • Touch the USER button to login to your account. touch GO to begin working out.

  • Page 21: Getting Started

    7XI APPS AND ENTERTAINMENT VIRTUAL ACTIVE SCREEN: NIKE + IPOD INSTRUCTIONS (7XE CONSOLES ONLY) REQUIREMENTS Nike + iPod – compatible iPod or iPhone (See www.apple.com/nikeplus for more information). Before syncing your Apple device, you must first create a free Nike + iPod account at www.nikerunning.com and have the Nike + iPod App turned on in the settings of your device.
  • Page 22 HRT Speed Based Serial Number T7XE AND T7XI CONSOLES: These sections allow users to manipulate default settings for the machines. Manager Mode may be accessed by pressing ENTER, 1, 0, 0, 1, Enter on the keypad. Engineering Mode may be accessed by pressing ENTER, 2, 0, 0, 1, Enter on the keypad.
  • Page 23 TREADMILL WORKOUTS MX_13_T5x_T7xe_T7xi_OM_Rev1_9.indd 44-45 3/27/13 10:22 AM...

  • Page 24: Workout Descriptions

    5K run is a level-based workout with a fixed distance of 5 Press the GO button and the treadmill will enter into a manual Your Matrix treadmill offers a variety of level-based Fat burn is a level-based workout that is designed to help kilometers.

  • Page 25: Heart Rate Control Workout Operation

    HEART RATE CONTROL WORKOUT OPERATION Your Matrix treadmill offers a variety of fitness tests-the Gerkin firefighter protocol, the WFI firefighter protocol, the Army, Navy, Your Matrix treadmill offers a heart rate control workout mode. The heart rate INCLINE workout mode allows the user Marines (USMC), and Air Force (USAF) as well as the Physical Efficiency Battery (PEB).
  • Page 26 WORKOUT DESCRIPTIONS SUBMAXIMAL TREADMILL EVALUATION CONVERSION TABLES: FITNESS TEST The WFI (Wellness Fitness Initiative) protocol is a modified Gerkin test used by firefighters to evaluate Males: VO2 max (ml/kg/min) To enter into this workout on the 5x, use the following guidelines. To aerobic fitness capacity as part of pre-employment testing and annual fitness testing.

  • Page 27: Product Specifications

    WORKOUT DESCRIPTIONS PEB - This fitness test is based on the running portion of the United States Federal Law Enforcement physical fitness PRODUCT SPECIFICATIONS test. The score (0-95) is determined by the time needed to FITNESS TEST complete a 1.5 mile run, the runner’s are and gender. The The Military Test programs and the Physical Efficiency user adjusts their speed and incline as they want.
  • Page 28 0.5 - 15* MPH / 0.8 - 24.1* KPH CONTACT & TELEMETRIC HR SENSORS DRIVE SYSTEM MOTOR MATRIX 5.0 HP AC DYNAMIC RESPONSE DRIVE SYSTEM™ MATRIX 5.0 HP AC DYNAMIC RESPONSE DRIVE SYSTEM™ MATRIX 5.0 HP AC DYNAMIC RESPONSE DRIVE SYSTEM™ MOTOR CONTROLLER...
  • Page 29 Matrix Fitness 1-866-693-4863 1600 Landmark Drive, www.matrixfitness.com Cottage Grove, WI 53527 Matrix T5x/T7xe/T7xi Treadmills Rev 1.9 | © 2013 Matrix Fitness MX_13_T5x_T7xe_T7xi_OM_Rev1_9.indd 56 3/27/13 10:22 AM...
