Altronix eBridge4PCRM Installation Manual page 3

Fig. 2
Structured
Cable from
IP Camera/Device
Coax
Cable from
eBridge4PCRM
Fig. 3
NetWay8M - Front Panel
Ethernet Switch
eBridge4PCRM
eBridge1PCTX
Multiple PoE camera connection:
eBridge4PCRM
PoC (PoE+ over Coax)
500m max.
PoC (PoE+ over Coax)
500m max.
PoC (PoE+ over Coax)
500m max.
PoC (PoE+ over Coax)
500m max.
+ PoE --
SHUTDOWN
Local Area Network (LAN)
or Laptop connection
Green LED
indicates
Power
Blue LED
indicates
Coax Connection
eBridge1PCTX PoE compliant
100m max.
PoE compliant
eBridge1PCTX
100m max.
PoE compliant
eBridge1PCTX
100m max.
PoE compliant
eBridge1PCTX
100m max.
Legend:
Coax
Structured Cable
PoE Camera
PoE Camera
PoE Camera
PoE Camera
- 3 -
