Altronix Pace1KRT Installation Manual

Pace1KRT
Long Range Single Pair (UTP) Ethernet Adapter Kit
Kit includes Pace1KR Receiver and Pace1KT Transceiver
Pace1KRT is a long range Ethernet adapter kit that transmits data and power via UTP (2-wire,
twisted pair) in a PoE(+) compliant format. Pace1KR receiver is powered via a PoE midspan/end-
span, such as the Altronix Netway series. The receiver passes the PoE compliant power over UTP
to the Pace1KT transceiver which, in turn, passes this power to an enabled IP camera/device. These
plug and play, cost-effective solutions facilitate IP devices that need to be installed at distances
greater such as in elevator shafts, tunnels, bridges, HVAC, etc.. supporting deployments over 1000m.
Input (Pace1KR Receiver):
• Powered by midspan or endspan.
PoE compliant to IEEE 802.3af (15W) and
PoE+ compliant to IEEE 802.3at (30W).
UTP Connection:
• Wire type: 2-wire (UTP).
• Speed: 10Mbps
• Distance: + 1000m, 18/2 AWG @ 10Mbps
(see Maximum Length of Cable Type vs.
Total Power Consumption, pg.3)
Ethernet Connection:
• Connectivity: RJ45, auto-crossover.
• Wire type: 4-pair CAT5e or higher.
• Distance: up to 100m from midspan to
Pace1KR receiver (headend),
100m from PaceKT transceiver to device
• Speed: 10/100BaseT, half/full duplex, auto
negotiation. PoE compliant to IEEE 802.3af
(15W) and PoE+ compliant to IEEE 802.3at
(30W) delivered to device by Pace1KR
Power provided by Pace1KR to Pace1KT
by PoE protocol.*
LED Indicators:
• Pace1KR and Pace1KT:
Link LED: Green, PoE Active
(left of UTP link)
Link LED: Green, Active Indicate
Data transmission (Next to Ethernet link)
• Pace1KR and Pace1KT: (RJ45 jack):
Yellow and Green LED IP Link status,
10/100Base-T/active.
*See note on Page 3.
Installation Guide
Overview:
Features:
Environmental:
• Operating Temperature:
Pace1KR / Pace1KT:
• Storage Temperature:
– 40ºC to 75ºC (– 40ºF to 167ºF).
• Relative humidity:
20 to 85%, non-condensing.
Functions:
• Auto detection and protection of legacy
non-PoE cameras/devices.
Applications:
• Utilize twisted pair for new installations
or retrofit of IP devices.
• Extend Network link distance in an
industrial environment over 1000m.
• Works with Megapixel, HD720, HD1080
and VGA (SD) cameras with proper
headend equipment.
Mechanical:
• Dimensions (W x L x H approx.):
Pace1KR and Pace1KT:
3.8" x 2.5" x 1"
(96.52mm x 63.5mm x 25.4mm).
– 40ºC to 75ºC (– 40ºF to 167ºF).
Rev. 012121
