  • Page 1 User Manual ITA-8100 / ITA-8120 Series EN 50155 10.4" / 12.1" Panel PC with Intel Atom® Processor for Railway Applications...
  • Page 2 No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. The information provided in this manual is intended to be accurate and reliable.
  • Page 3 Technical Support and Assistance Visit the Advantech website at http://support.advantech.com to obtain the latest product information. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before calling: Product name and serial number...
  • Page 4 CAUTION: The battery is at risk of exploding if incorrectly replaced. Replace only with the same type recommended by the manufacturer or an equivalent. Discard used batteries according to the manufacturer’s instructions. CAUTION: To avoid risk of electric shock, this equipment must only be con- nected to supply mains with protective earthing.
  • Page 5 Conformément à la norme CEI 704-1:1982, l’opérateur ne doit pas expérimenter un niveau sonore supérieur à 70 dB (A). AVERTISSEMENT: Ces consignes suivent la norme CEI 704-1. Advantech décline toute responsabilité concernant l'exactitude des déclarations con- tenues dans ce document. Declaration of Conformity This equipment has been tested and found to comply with the limits for a Class A dig- ital device, pursuant to part 15 of the FCC Rules.
  • Page 6 Warnings, Cautions, and Notes Warning! Warnings indicate conditions that may cause personal injury! Les avertissements indiquent des conditions qui, si elles ne sont pas observées, peuvent causer des dommages personnels (blessures). Caution! Cautions are included to help prevent hardware damage and data losses.

  • Page 7: Table Of Contents

    Safety and Environment................3 1.4.1 Safety.................... 3 1.4.2 Environment.................. 3 Panel and Cutout Dimensions..............4 Figure 1.1 ITA-8100 Series Dimensions Diagram ....... 4 Figure 1.2 ITA-8120 Series Dimensions Diagram ....... 5 Chapter Connectors and Function Keys ..7 Introduction ....................8 I/O Connectors ..................
  • Page 8 ITA-8100 / ITA-8120 User Manual viii...

  • Page 9: Chapter 1 General Information

    Chapter General Information  Introduction  Specifications  System Power  Safety and Environment  Panel and Cutout Dimensions...

  • Page 10: Introduction

    Cooling System: Fanless design  Dimensions (W x H x D):  ITA-8100 series: 310 x 214 x 70 mm (12.1 x 8.4 x 2.8 in) ITA-8120 series: 350 x 260 x 71.5 mm (13.8 x 10.2 x 2.8 in) 1.2.2 I/O Ports 1 x Power connector (M12 A-coded, 4-pin male) ...

  • Page 11: Lcd

    1.2.3 ITA-8100 Display Type TFT LED LCD Size (diagonal) 10.4" Resolution (Pixels) 1024 x 768 max. Luminance 500 nits Contrast Ratio 1000:1 Automatic with built-in light sensor / Manual Backlight Adjustment (Switched in BIOS) ITA-8100B Display Type TFT LED LCD Size (diagonal) 10.4"...

  • Page 12: System Power

    System Power Power Consumption:  ITA-8100: 30W ITA-8100B: 35W ITA-8120: 35W Input Voltage: 24V , 48V , 72V , 110V (±40%)  Safety and Environment 1.4.1 Safety FCC class A   UL 62368  EN 50155:2017  IP65 rating (front panel) ...

  • Page 13: Panel And Cutout Dimensions

    Panel and Cutout Dimensions ITA-8100  Unit: mm[inch] 310 [12.205] 295.65 [11.640] 70 [2.756] 92.5 [3.642] 295.65 [11.640] 70 [2.756] 14.33 [0.564] 267 [10.512] Panel Cutout 97.6 [3.843] Figure 1.1 ITA-8100 Series Dimensions Diagram ITA-8100 / ITA-8120 User Manual...
  • Page 14 ITA-8120  Unit: mm[ inch] 350 [13.780] 335.7 [13.215] 71.5 [2.815] 335.7 [13.215] 94 [3.701] 11.8 [0.466] 71.5 [2.815] Panel Cutout 99.1 [3.902] Figure 1.2 ITA-8120 Series Dimensions Diagram ITA-8100 / ITA-8120 User Manual...

  • Page 15: Chapter 2 Connectors And Function Keys

    Chapter Connectors and Function Keys  Introduction  I/O Connectors  Bezel Key Mapping...

  • Page 16: Introduction

    Introduction The following sections show the pin assignments for the I/O connectors and bezel key mapping to facilitate application integration. I/O Connectors AUDIO POWER COM (RS-422/485) Pin Number Definition Female 485-422_TX- 485-422_TX+ 422_RX+ M12-A-5P-F 422_RX- Pin Number Definition Female M12-A-4P-F ITA-8100 / ITA-8120 User Manual...
  • Page 17 Pin Number Definition Female M12-A-8P-F Pin Number Definition Female LAN_MDI0+ LAN_MDI0- LAN_MDI1+ LAN_MDI1- M12-X-8P-F LAN_MDI3+ LAN_MDI3- LAN_MDI2- LAN_MDI2+ AUDIO Pin Number Definition Male Line Out_R Line Out_L M12-A-5P-M MIC_R MIC_L Audio_GND POWER Pin Number Definition Male M12-A-4P-M ITA-8100 / ITA-8120 User Manual...

  • Page 18: Bezel Key Mapping

    Bezel Key Mapping Image Image Backlight on/ off; Reboot* SHIFT F2 LEFT SHIFT F3 RIGHT SHIFT F4 SHIFT F5 DOWN SHIFT F6 ENTER SHIFT F7 SHIFT F8 SHIFT F9 SHIFT F10 ITA-8100 / ITA-8120 User Manual...
  • Page 19 *Press the power button (K1) for less than 1 second: Backlight on/off *Press and hold the power button (K1) for 5 seconds: System reboot ITA-8100 / ITA-8120 User Manual...
  • Page 20 ITA-8100 / ITA-8120 User Manual...

  • Page 21: Chapter 3 Firmware And Bios Information

    Chapter Firmware and BIOS Information  DIO Setting Steps  Light Sensor Enabled and Dis- abled  Watchdog Sample Code...

  • Page 22: Dio Setting Steps

    DIO Setting Steps Table 3.1: DIO - Read DI0~4 Step Action Description Wait IBF clear 0x29A, BIT1, = 0 Write 0xE7 to 0x29A Send DIO command Wait IBF clear 0x29A, BIT1, = 0 Write 0x00 to 0x299 port Send Read DI command Wait OBF set 0x29A, BIT0, = 1 Read 0x299 port...

  • Page 23: Light Sensor Enabled And Disabled

    Table 3.4: DIO – LED High Step Action Description Wait IBF clear 0x29A, BIT1, = 0 Write 0xE7 to 0x29A Send DIO command Wait IBF clear 0x29A, BIT1, = 0 Write 0x03 to 0x299 port Send Write LED High Table 3.5: DIO – LED Low Step Action Description...

  • Page 24: Disable/Enable Light Sensor

    3.2.2 Disable/Enable Light Sensor Enter ‘Uncore Configuration’ in BIOS menu under ‘Chipset’ section. Inside, find ‘Brightness’ and set it to ‘Auto’ (enable light sensor) or ‘Manual’ (disable light sensor). ITA-8100 / ITA-8120 User Manual...
  • Page 25 Save desired configuration and exit BIOS to automatically restart system. ITA-8100 / ITA-8120 User Manual...

  • Page 26: Watchdog Sample Code

    Watchdog Sample Code #include <cstdlib> #include <sys/io.h> #include <unistd.h> #include <iostream> using namespace std; int OBF=0x01, IBF=0x02; int wait_OBF(int Port) int icount; for(icount=0;icount<0xFF;icount++) int iValue = inb(Port); if((iValue&OBF) == 0x01) return true; usleep(1000); cout << "wait_OBF failed\n"; cout.flush(); return false; int wait_IBF(int Port) int icount;...
  • Page 27 void SetWD() iopl(3); DummyPort(); inb(0x299); wait_IBF(0x29A); outb(0x89, 0x29A); wait_IBF(0x29A); outb(0x5E, 0x299); wait_IBF(0x29A); outb(0x00, 0x299); wait_IBF(0x29A); outb(0x89, 0x29A); wait_IBF(0x29A); outb(0x5F, 0x299); wait_IBF(0x29A); outb(0x64, 0x299); void StartWD() iopl(3); DummyPort(); outb(0x89, 0x29A); wait_IBF(0x29A); outb(0x57, 0x299); wait_IBF(0x29A); outb(0x04, 0x299); wait_IBF(0x29A); outb(0x28, 0x29A); void StopWD() iopl(3);...
  • Page 28 StartWD(); usleep(5000000); StopWD(); return 0; ITA-8100 / ITA-8120 User Manual...
  • Page 29 Appendix Panel Mounting...

  • Page 30: Appendix A Panel Mounting

    Panel Mounting M6x20L ITA-8100 / ITA-8120 User Manual...

  • Page 31: Appendix Bdc Power Connection

    Appendix DC Power Connection...

  • Page 32: Dc Power Connection

    DC Power Connection Caution! Only trained service personnel are authorized to install and remove the 24,48,72,110 V power source, and make connections and disconnec- tions between the V power source and protective earthing. The customer is responsible for ensuring that only trained service per- sonnel install or remove the 24,48,72,110 V power cable and grounded connection.

  • Page 33: Connexion Pour Source D'alimentation

    Connexion Pour Source D'alimentation Attention! Seul le personnel de service qualifié est autorisé à installer et à retirer la source d'alimentation de 24,48,72 ou 110 volts cc, ainsi qu'à effectuer les connexions et déconnexions de la source d'alimentation à 24,48,72 ou 110 volts cc, et à la mise à la terre. Il incombe au client de s'assurer que seul un personnel de maintenance qualifié...
  • Page 34 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2020...
