1.3.5.2 Symbols - function keys
Calculate distance
AUTO
Auto
AUTO
Automatic zero point 01, last measured
01
value
REL
Relative value
Stop / Accept
Repeat/ Continue
Delete last characteristic
Calibrate twin probe
Calibrate probe / groove
Calibrate ledge from below
Vertically contact a ledge
Select horizontal probe
Travel upwards
Contacting a bar from above
22
Calculating the symmetry between
2 planes
AUTO
Automatic calculation of the distance
0,00
Zero point, last measured value
ABS
Absolute value
Pause
Cancel
Delete all characteristics
?
Inferior calibrated value
Calibrate the probe / ledge
Calibrate ledge from above
Horizontally contact a ledge
Select vertical probe
Travel downwards
Contacting a shaft from above
