Technical data

Height measuring instrument 817 CLM
Measuring range
Application range
Measuring error
(at 20 °C, base plate according to DIN 876 /0,
styli 6.0 mm)
Perpendicularity error
(Base plate according to DIN 876 /0 and only in
conjunction with a corrected electronic measuring
system in the X-axis, with an incremental probe
Perpendicularity error mechanic
Repeatability +/- 2
Measuring force, probe 6.0 mm
Contacting speeds
Max. permissible manual positioning speed of the
measuring carriage
Drive mechanism
3-point air cushion
Compressed air supply
Interchangeable probes
Vertical measuring system of the column
Working- / operating temperature
Storage temperature
Permissible relative humidity (operating )
Permissible relative humidity (storage)
Weight
Thermometer / Sensor error limits
148
ca.
350 mm 600 mm
14"
respectively ca. 170 mm / 7"
1.8 + L/600 (L in mm)
< 5 µm < 6 µm
15 µm 20 µm
on a plane: 0.5 µm
1 N +/- 0.2 N
5, 8, 11, 15, 20 mm/sec. max. 40 mm/sec.
600 mm/s
motorizied
ca. 9 µm
integrated compressor
see accessories
incremental measuring system
10 °C ... 40 °C (50°F... 104 °F)
-10 °C...60 °C (14°F... 140 °F)
max. 65% (non-condensing)
max. 65 % (non-condensing)
25 kg (55.16 lbs) 30 kg (66.14 lbs)
+/- 0.5 °C (+/- 31.1°F)
1000 mm
24"
< 10 µm
in a bore: 1 µm
35 kg (77.16 lbs)
Mahr GmbH • Digimar 817 CLM
40"
30 µm
