5. When using stand-by batteries, they must be lead acid or gel type. Connect battery to the terminals marked [- - - BAT +]
(battery leads included), (Fig. 1, pg. 4 or Fig. 4, pg. 5).
Note: When batteries are not used, a loss of AC will result in the loss of output voltage.
6. For Supervised Models Only:
Connect appropriate signaling notification devices to AC Fail & Low Bat supervisory relay outputs marked
[N.C., C, N.O.] (Fig. 1a, pg. 4, Fig. 4a, pg. 5).
OLS250220/OLS257220 - Power Supply Board
Red (DC) Green (AC)
ON ON
ON OFF
OFF ON
OFF OFF
PD4/PD4CB/PD8/PD8CB - Power Distribution Module
Green Power Distribution Module Status
ON Normal operating condition.
OLS250220/OLS257220 - Power Supply Board
Terminal Legend Function/Description
L, G, N Connect 220VAC to these terminals: L to Hot, N to Neutral.
- - - DC + 24VDC @ 10A total supply current.
*AC FAIL Used to notify loss of AC power, e.g. connect to audible device or alarm panel. Relay normally
N.C., C, N.O. energized when AC power is present. Contact rating 1A @ 120VAC / 28VDC.
Used to indicate low battery condition, e.g. connect to alarm panel. Relay normally energized
*Low Battery when DC power is present.
N.C., C, N.O. Contact rating 1A @ 120VAC / 28VDC. Low battery threshold:
24VDC output threshold set @ approximately 21VDC.
- - - BAT + Stand-by battery connections. Maximum charge rate 0.7A.
*Note: Supervised models only.
PD4/PD4CB/PD8/PD8CB/PD16W/PD16WCB - Power Distribution Module
PD4/PD4CB
1P to 4P
1N to 4N
SMP10C24X220 Series
Power Supply Status
Normal operating condition.
Loss of AC. Stand-by battery supplying power.
No DC output.
Loss of AC. Discharged or no stand-by battery. No DC output.

Terminal Identification:

Terminal Legend
PD8/PD8CB
1P to 8P
1N to 8N

LED Diagnostics:

PD16W/PD16WCB
1P to 16P
1N to 16N
Function/Description
Positive DC power outputs.
Negative DC power outputs.
