Altronix SMP10C24X220 Installation Manual page 5

Fig. 4
Fig. 4a
AC FAIL
LOW BAT
15
Optional Rechargeable
SMP10C24X220 Series
Stand-by Battery
CAUTION: De-energize unit prior to servicing. For continued protection against risk of
electric shock and fire hazard replace fuse with the same type and rating 5A, 250V.
Ground
Lug
Wire Strap
(from Enclosure
to Door)
220VAC
power
mains
Door
Fig. 5
Used
on PTC
Models
AC FAIL
LOW BAT
15
Optional Rechargeable
Stand-by Battery
Power Distribution Module(s):
DC Output to devices
1P-16P Power Outputs,
1N-16N Common Outputs
common
1 2 3 4 5 6 7 8
outputs
protected
outputs
For continuous protection against
risk of fire replace fuses with
same type and rating.
3.5A 250V
Divider
Divider
Optional Rechargeable
Stand-by Battery
9 10 11 12 13 14 15 16
N
P
From
Power Supply Board
(Factory Installed)
PD16W/PD16WCB
Optional R
- 5 -
Stand-b
