Enclosure Dimensions - Altronix SMP10C24X220 Installation Manual

1.20"
(31mm)
1.40"
(36mm)
5.10"
(130mm)
(330mm)
5.10"
(130mm)
3.25"
(83mm)
1.0"
(25mm)
- 6 -

Enclosure Dimensions:

13.5" x 13" x 3.25" (342.9mm x 330.2mm x 82.55mm)
Enclosure accommodates up to two (2) 12VDC/7AH batteries.
1.40" 4.85"
(36mm) (123mm)
0.75"
(19mm)
13.0"
1.0"
(25mm)
4.85"
(123mm)
12.5"
(318mm)
11.0"
(279mm)
10.5"
(267mm)
1.40"
(36mm)
1.20"
(31mm)
3.25"
(83mm)
0.75"
(31mm)
(19mm)
0.9375"
(24mm)
0.9375"
(24mm)
3.25"
(83mm)
3.25"
(83mm)
1.0"
(25mm)
1.0"
(25mm)
SMP10C24X220 Series
