- Page 1 SMP10WP12 High Current Outdoor Power Supply/Charger - 12VDC @ 10A. Installation Guide More than just power. Rev. 020322 Installing Company: _______________ Service Rep. Name: __________________________________ Address: _____________________________________________ Phone #: __________________...
- Page 2 Enclosure Drawing and Dimensions ..........pg. 8 - 2 - SMP10WP12 Installation Guide...
- Page 3 Overview: Altronix SMP10WP12 is a 10A @ 12VDC, NEMA4 rated outdoor power supply. It is designed to be mounted outdoors to reduce installation and wiring costs while increasing efficiency and reliability to provide the power needed by the most demanding security and access control applications. Unit‘s unique NEMA 4/IP65 rated enclosure allows installation right at the outdoor equipment it is designed to power.
- Page 4 Fig. 1 Left Panel Right Panel Suggested Locations for Wire Entries Suggested Locations for Wire Entries Bottom Panel - 4 - SMP10WP12 Installation Guide...
- Page 5 Fig. 2 - SMP10WP12 Input 115VAC, 50/60Hz Ground Lug SMP10WP12 Installation Guide - 5 -...
- Page 6 (servicing) instructions in the literature accompanying the appliance. CAUTION: To reduce the risk of electric shock do not open enclosure. There are no user serviceable parts inside. Refer servicing to qualified service personnel. - 6 - SMP10WP12 Installation Guide...
- Page 7 This installation should be made by qualified service personnel. This product contains no serviceable parts. PMK1 is intended for use with Altronix outdoor rated power supplies or accessories housed in WP1, WP3 and WP4 enclosures. Brackets are designed for use with the Wormgear Quick Release Straps (two included).
- Page 8 MOUNTING PANEL 0.08” (2mm) CARBON STEEL SHEET 4.21” (107mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty IISMP10WP12...
