Note And Warning Symbols; The Scope Of This Document - Thinklogical TLX20 Product Manual

Note and Warning Symbols

Throughout this manual you will notice certain symbols that bring your attention to important information.
These are Notes and Warnings. Examples are shown below.
Note: Important Notes appear in blue text preceded by a yellow exclamation point
symbol, as shown here.
A note is meant to call the reader's attention to helpful information at a point in the text that is relevant to
the subject being discussed.
Warning!
red stop sign, as shown here.
A warning is meant to call the reader's attention to critical information at a point in the text that is
relevant to the subject being discussed.
BEFORE STARTING ANY PROCEDURE, IT IS RECOMMENDED
THAT YOU READ THE INSTRUCTIONS THOROUGHLY!

The Scope of This Document

This Product Manual is intended to provide customers with a full overview of the features, functions,
usage and support for Thinklogical's TLX10 CATx Extender Transmitter (TLX-TCF-U00D10) and
Receiver (TLX-RCF-U00D10), capable of extending a single Video Display and Data at a rate of
4096x2160 @ 30Hz for up to 100m over a single CAT6a 23 AWG Cable...
...and for Thinklogical's TLX20 CATx Extender Transmitter (TLX-TCF-U00D20) and Receiver (TLX-
RCF-U00D20), capable of extending a single Video Display and Data at a rate of 4096x2160 @ 60Hz for
up to 100m over a pair of CAT6a 23 AWG Cables.
