Rectifying faults

Vent coolant circuit

7.4 Vent coolant circuit
Coolant tank and quick connect coupling of coolant supply and return are only fitted in machines
with water cooling.
To vent the cooling system always use the blue coolant connection, which is located as deep as
possible inside the system (close to the coolant tank)!
44
1
max
blau / blue
2
0
l
3
KLICK
CLICK
092-007861-00000
4
5
6
7
Figure 7-3
0
l
ca. 5s
0
l
KLICK
CLICK
