INDOOR/OUTDOOR RECESSED ELECTRIC FIREPLACE
SAFETY INFORMATION AND OPERATIONS MANUAL
Wall Switch Ready for on/off operation, no remote control
option for this fireplace.
Read these instructions completely before beginning instal-
lation. Failure to follow them could result in serious injury.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
NOVA 60
Advertisement
Table of Contents
Related Manuals for Modern Flames NOVA 60
Summary of Contents for Modern Flames NOVA 60
- Page 1 NOVA 60 INDOOR/OUTDOOR RECESSED ELECTRIC FIREPLACE SAFETY INFORMATION AND OPERATIONS MANUAL Wall Switch Ready for on/off operation, no remote control option for this fireplace. Read these instructions completely before beginning instal- lation. Failure to follow them could result in serious injury.
- Page 2 USER INSTRUCTIONS TABLE OF CONTENTS Important Instructions ........2 Power Data ..........3 Contractor Instructions ......... 2 Locating Fireplace ........4 Unpacking and Testing ........ 2 Installation ........... 4 Product Dimensions ........3 Operation ............ .6 Box Contents ..........3 Service Parts ..........
- Page 3 57 1/4” W x 17 7/8” H x 5” D POWER DATA Model Voltz/HZ Amps Lamps Rotor motor AC 120V/60Hz DC 12V NOVA 60 1.5 Amps CCW 15/18 r/min BOX CONTENTS Nova 60 Fireplace Coal Bed Media Installation Hardware Installation Manual/Owners Manual ...
- Page 4 This electric fireplace must be installed framed in to a wall. The Modern Flames Nova 60 is gasket sealed around the perimeter and can be used in interior or exterior applications. Modern...
- Page 5 Recessed Installation: Framing Dimensions 1. Prepare frame opening according to chart. Nova 60 57 1/4” W x 17 1/8” H x 5” D Frame opening is larger than the fire unit. 2. Set the fireplace on a clean flat surface with the glass face face-up. Start from any corner of the decorative glass face and gently pull up until the ball-catches start to separate.
-
Page 6: Service Parts
SERVICE PARTS PART# DESCRIPTION NOVA-SM2 SPINDLE MOTOR NOVA-LED60 LED LIGHT STRING NOVA 60 NOVA-PA12 POWER ADAPTOR 12V DC NOVA-PCB2 PC BOARD NOVA60G-FACE BLACK GLASS DECORATIVE FACE NOVA60BS-FACE... - Page 7 MAINTENANCE NOTES...
- Page 8 © 2016 www.modernflames.com Please dispose of properly.
