ZCR 3824
SAFETY INFORMATION AND OPERATIONS MANUAL
Read these instructions completely before beginning installation. Failure to follow them
could cause a heater malfunction resulting in serious injury and/or property damage.
WARNING: All electric heaters have hot and arcing or sparking parts inside. Do not use it
in areas where gasoline, paint or flammable liquids are or are stored.
© 2014
This fireplace meets the construction and safety standards of H.U.D. for application in
www.modernflames.com
manufactured homes when installed according to these instructions.
Please dispose of properly.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
