- Page 1 Ambiance CLX Electric Series AL1000CLX • AL1500CLX • AL2000CLX AL2500CLX • AL3600CLX INSTALLATION/SERVICE INSTRUCTIONS FOR USE IN UNITED STATES AND CANDA...
- Page 2 Read these instructions completely before beginning installation. Failure to follow them could cause a heater malfunction resulting in serious injury and/or property damage. WARNING: All electric heaters have hot and arcing or sparking parts inside. Do not use it in areas where gasoline, paint or flammable liquids are or are stored. This fireplace meets the construction and safety standards of H.U.D.
-
Page 3: Table Of Contents
USER INSTRUCTIONS TABLE OF CONTENTS Important Instructions ........3 Operation ........... 10 Product Dimensions ........5 Service Parts ..........11 Box Contents ..........5 Frequently Asked Questions ...... 12 Listing Approvals ......... 6 Troubleshooting ......... 13 Unpacking and Testing ........ 6 Cleaning and Maintenance Instructions .. - Page 4 USER INSTRUCTIONS IMPORTANT INSTRUCTIONS 12.To prevent possible fire, do not block air 24.Heater must not be located immediately inlets or outlets in any manner. Do not use below a socket outlet. on soft surfaces, like a bed, where 25.The appliance is not to be used by children openings may become blocked.
-
Page 5: Product Dimensions
AL1000CLX 559mm W x 254mm H 1016mm W x 648mm H 616mm W x 489mm H x 140mm D AL1500CLX 1067mm W x 254mm H 1524mm W x 648mm H 1124mm W x 489mm H x 140mm D AL2000CLX 1575mm W x 254mm H 2032mm W x 648mm H 1632mm W x 489mm H x 140mm D... -
Page 6: Listing Approvals
USER INSTRUCTIONS LISTING APPROVALS AL-3600 CLX AL-2500 CLX AL-2000 CLX AL-1500 CLX AL-1000 CLX Volts/HZ AC 220V/50Hz AC 220V/50Hz AC 220V/50Hz AC 220V/50Hz AC 220V/50Hz Amps 15 Amps 15 Amps 15 Amps 15 Amps 15 Amps AC 220V/50Hz AC 220V/50Hz AC 220V/50Hz AC 220V/50Hz AC 220V/50Hz... -
Page 7: Locating Fireplace
INSTALLATION LOCATING FIREPLACE CAUTION: Do not locate in a moist room such as a bathroom or laundry room. CAUTION: Wear gloves safety glasses for protection during installation and maintenance. This electric fireplace can be installed framed in to a wall. Install at least 1 meter from the floor and any combustibles such as carpet and drapes. - Page 8 635mm W x 502mm H x cord 100mm D 4. Hang the face on the fire unit. Make certain AL1500CLX 1143mm W x 502mm H x that the hooks from the on the backside of the 100mm D glass face are secured on all 4 studs on the fire...
- Page 9 Use the chart below to see proper distance between the screws used to hold the mount- ing bracket. Power cord AL1000CLX 450mm AL1500CLX 756mm AL2000CLX 1264mm 5. Hang the glass face on the fire unit. Make certain that the hooks from the on the backside AL2500CLX...
-
Page 10: Operation
OPERATION OPERATION On the bottom of the unit is a main power switch. Switch this on to begin using the fireplace. Directly below the flame, on the right hand side are 3 small LED status lights and 3 buttons. Power Heat Backlight When all indicator lights are off, pressing on... -
Page 11: Service Parts
MAINTENANCE AL CLX SERVICE PARTS ITEM PHOTO COMMENTS PRINTED CIRCUIT BOARD CONTROLS LOW MFPCB1 VOLTAGE AND HIGH VOLTAGE FUNCTIONS MFTC1 LCD TOUCH CONTROL MFRR1 REMOTE CONTROL IR RECEIVER MF12VT1 TRANSFORMER 1 AMP MF12VT3 TRANSFORMER 3 AMP MFHF12015 HEATER FAN 220 V 1.5kW MFPHFAL40 MFPHFAL60 MFPHFAL80... -
Page 12: Frequently Asked Questions
MAINTENANCE AL40WMB WALL MOUNT BRACKET AL1000 AL60WMB WALL MOUNT BRACKET AL1500 AL80WMB WALL MOUNT BRACKET AL2000 AL100WMB WALL MOUNT BRACKET AL2500 AL144WMB WALL MOUNT BRACKET AL3600 ALGLS40 GLASS FACE AL1000 ALGLS60 GLASS FACE AL1500 ALGLS80 GLASS FACE AL2000 ALGLS100 GLASS FACE AL2500 ALGLS144 GLASS FACE AL3600 FREQUENTLY ASKED QUESTIONS... -
Page 13: Troubleshooting
MAINTENANCE TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION A. Fireplace is not plugged in to an A. Check plug electrical outlet B. Breaker tripped or outlet has no B. Reset breaker, test outlet for power power C. Turn main power switch to the C. -
Page 14: Cleaning And Maintenance Instructions
MAINTENANCE PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION A. Disconnect unit from power A. Wiring is loose source and inspect for loose Flame is not visible when connections unit is turned on B. Motherboard is defective B. Replace motherboard A. Disconnect unit from power A. -
Page 15: Wiring Diagram
MAINTENANCE WIRING DIAGRAM NOTES... - Page 16 © 2012 www.modernflames.com Please dispose of properly.
