Modern Flames Landscape Pro Slim LPS-5614V2 Installation Manual

Hide thumbs Also See for Landscape Pro Slim LPS-5614V2:
Table of Contents

Advertisement

Quick Links

Download this manual
Landscape Pro Slim Electric Fireplace
Model#
Approved for Indoor and Outdoor Use
Read and understand this entire owner's manual, including all safety
information, before plugging in or using this product. Failure to do so
WARNING
could result in fire, electric shock, or serious personal injury. Don't
spray water directly on to product. Clean with damp cloth or duster.
Keep this owner's manual for future reference. If you sell or give this
CAUTION
product away, make sure this manual accompanies this product.
AFFIX SERIAL NUMBER LABEL
HERE FOR FUTURE REFERENCE
LPS-4414V2
LPS-8014V2
Installation Manual
Rated: 120VAC 60Hz 5,000 BTUs
LPS-5614V2
LPS-9614V2
LPS-6814V2
07-00012 REV C
V2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Landscape Pro Slim LPS-5614V2 and is the answer not in the manual?

Questions and answers

Related Manuals for Modern Flames Landscape Pro Slim LPS-5614V2

Summary of Contents for Modern Flames Landscape Pro Slim LPS-5614V2

  • Page 1 Landscape Pro Slim Electric Fireplace Model# LPS-4414V2 LPS-5614V2 LPS-6814V2 LPS-8014V2 LPS-9614V2 Installation Manual Approved for Indoor and Outdoor Use Rated: 120VAC 60Hz 5,000 BTUs Read and understand this entire owner’s manual, including all safety information, before plugging in or using this product. Failure to do so WARNING could result in fire, electric shock, or serious personal injury.

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION! WARNING When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: 1. Read all Instructions before installing or using the heater. 2. This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, etc.

  • Page 3: Consignes Importantes

    CONSIGNES IMPORTANTES ATTENTION Lors de l'utilisation d'appareils électriques, des précautions de base doivent toujours être suivies pour réduire les risques d'incendie, d'électrocution et de blessures, notamment les suivantes : 1. Lisez toutes les instructions avant d'installer ou d'utiliser le radiateur. 2.
  • Page 4 USER INSTRUCTIONS POWER DATA LPS-4414V2 LPS-5614V2 LPS-6814V2 LPS-8014V2 LPS-9614V2 Volts/HZ Amps AC 120V AC 120V AC 120V AC 120V AC 120V 60Hz 13 Amp 60Hz 13 Amp 60Hz 13 Amp 60Hz 13 Amp 60Hz 13 Amp Heater AC 120V 1465W AC 120V 1465W AC 120V 1465W AC 120V 1465W...

  • Page 5: Product Guide

    PRODUCT GUIDE ⁄ " Model Viewing Area Firebox Dimensions Framing Dimensions LPS-4414V2 ⁄ " W x 13 ⁄ " H ⁄ " W x 23 ⁄ " H x 5 ⁄ " D ⁄ " W x 24 ¹⁄ " H x 6" D 1111 mm W x 356 mm H 1124 mm W x 603 mm H x 141 mm D 1130 mm W x 613 mm H x 152 mm D LPS-5614V2...

  • Page 6: Parts And Hardware

    PARTS AND HARDWARE (1) L-Metal Mounting (1) Canyon (1) Fireplace (1) Owners Manual Bracket Set (1) Remote Driftwood Logs Set (1) Front Glass (1) Battery Tool (1) CR2025 Battery (1) Suction Cup (1) Trim Wall Mount Smoke Clear (1) Touch Control Acrylic Crystals Pkg Acrylic Stones Pkg (Sold Separately)

  • Page 7: Installation

    INSTALLATION Select a suitable location that is away from drapes, furniture, and high traffic areas. NOTE: Follow all National and local electrical codes. This product includes a GLASS panel. Always use extreme caution when handling glass. Failure to do so could result in personal injury or property damage. Due to the many different materials used on different walls, it is highly recommended that you consult your local builder before you install this fireplace.

  • Page 8: Built-In Installation

    BUILT-IN INSTALLATION Fully Recessed Installation (Single Sided) 1. This installation is optimized for a 2x6 framed wall. Prepare the framed opening according to the framing dimensions chart (pg 4). *Provide appropriate dedicated circuit for hardwire install at the top right of framed opening. 2.
  • Page 9 BUILT-IN INSTALLATION Partial Recessed Installation 1. This installation is optimized for a 2x4 framed wall. Prepare the framed opening according to the framing dimensions chart on page 4. *Provide appropriate dedicated circuit for hardwire install at the top right of framed opening. 2.

  • Page 10: Outdoor Installation Requirements

    OUTDOOR INSTALLATION REQUIREMENTS The LPS Series electric fireplaces from Modern Flames LLC have been tested and approved for installation outdoors under a patio cover and away from direct water contact or direct sun light. Modern Flames LLC standard warranty applies if installed per instructions. All electrical wiring shall be to local building codes.

  • Page 11: Side Protection

    OUTDOOR INSTALLATION REQUIREMENTS Side Protection: Side distance (SD) must be 50% (or more) of the height(H). If: H=6’ Then: SD=3’ minimum (6’ x 50%=3’) Note: H taken from bottom of fireplace.
  • Page 12 LOG SETS #1 LOG #2 LOG #3 LOG #5 LOG #4 LOG #6 LOG #7 LOG #8 LOG #11 LOG #10 LOG #12 LOG #15 LOG #9 LOG #13 LOG #16 LOG #14 LOG LANDSCAPE PRO SLIM – LOG SET SIZES 44 –...

  • Page 13: Log Placement

    LOG PLACEMENT LANDSCAPE PRO SLIM – LOG PLACEMENT 44" – 56" – 68" – 80" – 96" LPS 44" – Set contains 6 logs LPS 56" – Set contains 8 logs LPS 68" – Set contains 10 logs LPS 80" – Set contains 12 logs LPS 96"...

  • Page 14: Hard Wiring

    HARD WIRING A qualified electrician must wire this fireplace to a dedicated 110`120 volt, 20 amp circuit. NOTE:A dedicated 20 Amp (or higher) and breaker is required. The appliance must be electrically connected and grounded in accordance with local codes. In the abscence of local codes, use the current CSA C22.1 Canadian Electrical Code in Canada or the current ANSI/NFPA 70 National Electrical Code in the USA.
  • Page 15 INSTALLING MEDIA AND FRONT GLASS 1. Remove screws from top of glass bracket. Use the small suction cup provided in the hardware kit to lean glass towards the front. Then lift glass up and away. Place glass in soft, safe area.

  • Page 16: Remote Control Operation

    . If the fireplace is on, this button will act as a Home reset and bring all colors back to the default Modern Flames' signature color. This will cycle the heater between high, Heat low and off .

  • Page 17: Setting Controls

    SETTING CONTROLS Manual Controls Toggle Switch: The fireplace has a main toggle switch located next to the manual controls. The fireplace has manual controls located next to the The toggle switch is in front of the glass on toggle switch, in front of the glass on the top the top right side of the viewing area.
  • Page 18 SETTING CONTROLS NOTE: When silent mode is selected, a tone will still -AP Mode: While the fireplace is ON, long press be present for performing system functions the Preset Color button for 6 seconds. Two such as remote pairing or Wi-Fi pairing. audible beeping tones will sound and then only the FLAME LIGHTS and nothing else will turn to Placing in Wi-Fi Paring Mode:...
  • Page 19 WI-FI REMOTE Sync This is a synchronization selector, used to synchronize the current color on the color wheel to all of the zones (Flame/Ember Bed/Downlight). Grayed out SYNC is when synchronization is “OFF”. Green SYNC is when synchronization is “ON”. Color Wheel This is the color adjustment wheel for all zones.

  • Page 20: Mode Sub Menu

    Same as remote control blue monochrome fade cycle. PRESET MENU > Seven Color Demo Same as remote control, 7 color jump > Modern Flames Original cycles: R->G->B->RG->RB->GB->RGB. Modern Flames Orange (Static). > Three Color Demo Same as remote control, 3 color jump >...
  • Page 21 WI-FI REMOTE Timer Pressing the timer button will pop up a sub-menu with 10 options to choose from: 0.5-1-2-3-4-5-6-7-8 hours-cancel. Once the selected time has elapsed, the fireplace will turn off. (default) Ambience Setting The Ambience Setting button will open up a second window where customizations can be performed, including temperature scale setting...
  • Page 22 WI-FI REMOTE Power Turn On Cancel HEAT PROGRAM SUB MENU CONTINUED Heat Level > Power Sets fireplace status (no heat) OFF/ON. > Heat Level Sets Heat Level: OFF/LOW/HIGH. High > Temperature Cancel Temperature Level for the heater to turn on if the ambient temperature falls below the set temperature (High Heat).
  • Page 23 WI-FI REMOTE > Mode Color Mode color: In the Static mode, only one color can be selected. After clicking the color symbol, you can change to additional colors. When using the Jump/Gradient feature, 8 colors can be programmed by clicking “+” color. By adjusting the color sliders, select the corresponding RGB value to obtain the desired color...
  • Page 24 WI-FI INITIAL LOG-IN Search for and install the “MODERN FLAMES” app from Google Play or Apple App store or scan the QR code. STEP STEP > After Download & Installed Login to Modern Flames app. > App Example...
  • Page 25 WI-FI PAIRING STEP STEP > Once Opened and Logged In > Select Fireplace From the home page, select the add “+” Select series of fireplace that will be symbol. pairing too and follow instructions.
  • Page 26 WI-FI REMOTE STEP STEP > Wi-Fi Information > Ensure Fireplace is ON If pairing via Wi-Fi you must use 2.4 GHz Using the fireplace manual touch Wi-Fi, and must have information filled controls, turn ON the fireplace. out to move to next step.
  • Page 27 WI-FI REMOTE STEP STEP > Place Fireplace in Pairing Mode > Wi-Fi Pairing Confirmed Once fireplace is “ON”, place fireplace in EZ pairing mode is confirmed with a Wi-Fi pairing mode following the instruc- single audible beeping tone is heard tions for pairing mode on the APP.
  • Page 28 WI-FI REMOTE STEP STEP Wi-Fi Wi-Fi > Pairing > Device Paired Successfully Device & APP should now begin to pair. NOTE: Do not turn off or disconnect the Depending on Wi-Fi this can take up the fireplace from power while pairing the entire 2 minutes to pair, or it may need Wi-Fi or performing updates.

  • Page 29: Maintenance

    MAINTENANCE...

  • Page 30: Troubleshooting

    TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION A. Breaker tripped or circuit has no A. Reset breaker, test circuit for power, check power power switch Nothing comes on B. Internal component is frozen B. Turn power off at the main breaker for 60 and needs to be reset seconds.

  • Page 31: Frequently Asked Questions

    Q. How do I reset the Unit? A. Turn power off at the breaker for 1 minute. Q. How do I install the Optional Wall Control and Wi-Fi App? A. Optional wall control & Wi-Fi app instructions available for download on Modern Flames’ website...

  • Page 32: Fcc Caution

    FCC CAUTION This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
  • Page 33 NOTES __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________...
  • Page 34 NOTES __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________...
  • Page 35 NOTES __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________...
  • Page 36 Copyright © 2023 RPG Brands (Modern Flames). All rights reserved. Products and specifications subject to change without notice. The product images shown are for illustration purposes only and may not be an exact representation of the product. 082023...
