- Page 1 Landscape Fullview Series LFV2-40/15-SH • LFV2-60/15-SH• LFV2-80/15-SH LFV2-100/15-SH • LFV2-120/15-SH INSTALLATION/SERVICE INSTRUCTIONS FOR USE IN UNITED STATES AND CANADA...
- Page 2 USER INSTRUCTIONS LANDSCAPE FULLVIEW SERIES GENERATION 2 LFV2-40/15-SH • LFV2-60/15-SH• LFV2-80/15-SH LFV2-100/15-SH • LFV2-120/15-SH SAFETY INFORMATION AND OPERATIONS MANUAL Read these instructions completely before beginning installation. Failure to follow them could cause a heater malfunction resulting in serious injury and/or property damage.
-
Page 3: Table Of Contents
USER INSTRUCTIONS TABLE OF CONTENTS Important Instructions ........3 Operation ........... 9 Power Data ..........4 Service Parts ..........10 Product Guide ..........4 Troubleshooting ......... 12 Box Contents ..........5 Frequently Asked Questions ...... 13 Locating Fireplace ........5 Cleaning and Maintenance Instructions .. -
Page 4: Power Data
USER INSTRUCTIONS POWER DATA LFV2-40/15-SH LFV2-60/15-SH LFV2-80/15-SH LFV2-100/15-SH LFV2-120/15-SH Volts/HZ AC 120V/60Hz AC 120V/60Hz AC 120V/60Hz AC 120V/60Hz AC 120V/60Hz Amps 15 Amps 15 Amps 15 Amps 15 Amps 15 Amps AC 120V/60Hz AC 120V/60Hz AC 120V/60Hz AC 120V/60Hz AC 120V/60Hz... -
Page 5: Box Contents
INSTALLATION BOX CONTENTS 1 Fire Unit L Metal Nail- ing Flanges (with screws) 1 Remote 1 Piece Trim Deco Trim LOCATING FIREPLACE CAUTION: Do not locate in a moist room such as a bathroom or laundry room. CAUTION: Wear gloves and safety glasses for protection during installation and mainte- nance. - Page 6 INSTALLATION Model LFV2-40/15-SH 23” 55 3/4” 12” LFV2-60/15-SH 23” 75 3/4” 12” LFV2-80/15-SH 23” 95 3/4” 12” LFV2-100/15-SH 23” 115 3/4” 12” LFV2-120/15-SH 23” 135 3/4” 12” 1. Prepare the framed opening according to the chart above. Provide a flexible 15 amp 120 volt circuit for hard wire installation.
- Page 7 INSTALLATION 4. Install the fire unit in the framed opening with a minimum 1 ¼ drywall screws to secure the unit. 5. Mask the exposed fire unit during the drywall process. Install drywall to the drywall stops on the perimeter of the fire insert. For more information on the drywall stops see the Product Guide on page 4.
- Page 8 OPERATION Installing remote touch control 1. Locate and remove the access door on the rear right side of the fire unit. 2. Locate the remote touch control directly inside the access panel. Pull the touch control through the access panel and replace the access door.
-
Page 9: Operation
MAINTENANCE OPERATION The unit is hardwired and has no main switch. (Caution: If servicing this unit, turn off power at the main circuit breaker.) An optional tethered wall control switch is included, refer to installation instructions to relocate the tethered wall control switch to a wall location. Power Heat Dimmer/Color... -
Page 10: Service Parts
MAINTENANCE LANDSCAPE SERVICE PARTS ITEM PHOTO COMMENTS PRINTED CIRCUIT BOARD CONTROLS LOW MFPCB2 VOLTAGE AND HIGH VOLTAGE FUNCTIONS MFTC2 LCD TOUCH CONTROL MFRR2 REMOTE CONTROL IR RECEIVER MF12VT3 TRANSFORMER HEATER FAN 120 V 1500 WATTS RIGHT HF12015-R HAND HF12015-L HEATER FAN 120 V 1500 WATTS LEFT HAND HC120V750 HEATER 120 V 750 WATTS MFSM120... - Page 11 MAINTENANCE MFPLS240 LED LED LIGHT STRIP LS2 40 MFPLS260 LED LED LIGHT STRIP LS2 60 MFPLS280 LED LED LIGHT STRIP LS2 80 MFPLS2100 LED LED LIGHT STRIP LS2 100 MFPLS2120 LED LED LIGHT STRIP LS2 120 MFPLS240 LED EMBER BED LED LIGHT STRIP LS2 40 MFPLS260 LED EMBER BED LED LIGHT STRIP LS2 60 MFPLS280 LED...
-
Page 12: Troubleshooting
MAINTENANCE TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION A. Breaker tripped or circuit has no A. Reset breaker, test circuit for power power B. Turn power off at the main B. Internal component is frozen breaker for 20 seconds. Turn power Nothing comes on (touch and needs to be reset back on. -
Page 13: Frequently Asked Questions
MAINTENANCE PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION A. Disconnect unit from power A. Wiring is loose source and inspect for loose Flame is not visible when connections unit is turned on B. Motherboard is defective B. Replace motherboard A. Disconnect unit from power A. -
Page 14: Cleaning And Maintenance Instructions
MAINTENANCE CLEANING AND MAINTENANCE INSTRUCTIONS There is very little maintenance involved with your electric fireplace. Please follow the few points be- low: On a semi-annual basis remove the glass face of the fireplace and dust the fire unit with a dry ... - Page 15 MAINTENANCE NOTES...
- Page 16 © 2013-2017 www.modernflames.com Please dispose of properly.
