INSERT FIRE 3824
SAFETY INFORMATION AND OPERATIONS MANUAL
Read these instructions completely before beginning installation. Failure to follow them
could cause a heater malfunction resulting in serious injury and/or property damage.
WARNING: All electric heaters have hot and arcing or sparking parts inside. Do not use it
in areas where gasoline, paint or flammable liquids are or are stored.
This fireplace meets the construction and safety standards of H.U.D. for application in
manufactured homes when installed according to these instructions.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Advertisement
Table of Contents
Related Manuals for Modern Flames INSERT FIRE 3824
Summary of Contents for Modern Flames INSERT FIRE 3824
- Page 1 INSERT FIRE 3824 SAFETY INFORMATION AND OPERATIONS MANUAL Read these instructions completely before beginning installation. Failure to follow them could cause a heater malfunction resulting in serious injury and/or property damage. WARNING: All electric heaters have hot and arcing or sparking parts inside. Do not use it in areas where gasoline, paint or flammable liquids are or are stored.
-
Page 2: Table Of Contents
USER INSTRUCTIONS TABLE OF CONTENTS Important Instructions ........2 Installation ..........6 Power Data ..........3 Operation ........... 8 Product Dimensions ........4 Frequently Asked Questions ...... 9 Box Contents ..........4 Troubleshooting ......... 9 Unpacking and Testing ........ 5 Cleaning and Maintenance Instructions .. -
Page 3: Power Data
1500 watts. 13. This heater is not intended for use in 16. SAVE THESE INSTRUCTIONS bathrooms, laundry areas and similar indoor POWER DATA Insert Fire 3824 Volts/HZ Amps AC 120V/60Hz 15 Amps Heater AC 120V/60Hz 750W/1500W Lamps... -
Page 4: Product Dimensions
USER INSTRUCTIONS PRODUCT DIMENSIONS 19” 29” 10 1/2” Insert Fire 3824—Front View 29” W x 19” H x 10 1/2” D BOX CONTENTS 1 Fire Unit 1 Remote Optional trim... -
Page 5: Unpacking And Testing
INSTALLATION UNPACKING AND TESTING This heater is for use on 120 volts. The cord has a plug as shown at A. An adapter as shown at C is available for connecting three- blade grounding-type plugs to two-slot recep- Grounding Pin tacles. -
Page 6: Installation
INSTALLATION INSTALLATION WARNING - RISK OF FIRE! WARNING: If the information in these in- The power cord must not be pinched or structions is not followed exactly, a fire against a sharp edge. Secure cord to or explosion may result causing property avoid tripping or snagging to reduce the damage, personal injury or death. - Page 7 INSTALLATION 1. Make sure the fireplace is clean and free of debris. Install the fire feature according to the instructions included with that feature (the fire features include log set or contemporary glass burner.) Plug in the fire unit. 2. Simply slide the fire unit in to your existing fireplace.
-
Page 8: Operation
OPERATION OPERATION On the lower right corner of the right side of the fire unit, near the power cord, is the main power switch. Switch this on to begin using the fireplace. Directly below the flame, on the right hand side are 3 control switches. -
Page 9: Frequently Asked Questions
MAINTENANCE FREQUENTLY ASKED QUESTIONS Q. How do you program the remote control? A. The remote comes pre-programmed. No programming is necessary. Q. What distance can the remote be used from the fireplace? A. Optimal distance for the remote control is within 10 yards. Q. -
Page 10: Cleaning And Maintenance Instructions
MAINTENANCE PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION A. Fireplace is not plugged in to an A. Check plug electrical outlet B. Breaker tripped or outlet has no B. Reset breaker, test outlet for power power C. Turn main power switch to the C. -
Page 11: Wiring Diagram
MAINTENANCE WIRING DIAGRAM Wiring Diagram NOTES... - Page 12 © 2013 www.modernflames.com Please dispose of properly.
