SAFETY INFORMATION AND OPERATIONS MANUAL
Read these instructions completely before beginning installa-
tion. Failure to follow them could cause a heater malfunction
resulting in serious injury and/or property damage.
WARNING: All electric heaters have hot and arcing or sparking
parts inside. Do not use it in areas where gasoline, paint or
flammable liquids are or are stored.
This fireplace meets the construction and safety standards of
H.U.D. for application in manufactured homes when installed
according to these instructions.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
AMBIANCE LINEAR 40
AMBIANCE LINEAR 60
AMBIANCE LINEAR 100
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Modern Flames AMBIANCE LINEAR 40
Summary of Contents for Modern Flames AMBIANCE LINEAR 40
- Page 1 AMBIANCE LINEAR 40 AMBIANCE LINEAR 60 AMBIANCE LINEAR 100 SAFETY INFORMATION AND OPERATIONS MANUAL Read these instructions completely before beginning installa- tion. Failure to follow them could cause a heater malfunction resulting in serious injury and/or property damage. WARNING: All electric heaters have hot and arcing or sparking parts inside.
-
Page 2: Table Of Contents
Table of Contents Safety..........2 Installation........6 Listing Approvals.......3 Operation.........9 Product Dimensions......4 Service Parts……………………….10 Box Contents………......5 Frequently Asked Questions……..12 Unpacking and Testing…....5 Troubleshooting……………………13 Locating Fireplace......6 Safety Do not install fireplace directly WARNING: Improper installation, on carpet or similar surface adjustment, alteration, service or which may restrict air circula- maintenance can cause injury or tion beneath unit. -
Page 3: Listing Approvals
Safety indoor locations. Never locate heater persons. where it may fall into a bathtub or 16. Avoid the use of an extension cord other water container. because the extension cord may 9. Do not run cord under carpeting. Do overheat and cause a risk of fire. not cover cord with throw rugs, run- However, if you have to use an ex- ners or the like. -
Page 4: Product Dimensions
Product Dimensions AL CLX 40 40” W x 25.5” H x 3.48” D AL CLX 60 60” W x 25.5” H x 3.48” D AL CLX 100 100” W x 25.5” H x 3.48” D... -
Page 5: Box Contents
Box Contents 1 Mounting 4 Wall Anchors Bracket 8 Small Washer Head Screws 1 Fire Unit 4 Large Washer Head Screws 1 Glass Face 1 Remote 3 L-metal Brackets Unpacking and Testing Carefully remove unit from box. Prior to WARNING: Do not operate the permanently installing unit, test to make unit if it is damaged or has mal- sure unit operates properly. -
Page 6: Locating Fireplace
Locating Fireplace CAUTION: Do not expose the heater to the elements (such as rain, etc.) CAUTION: Wear gloves safety glasses for protection during installation and mainte- nance. This electric fireplace can be in- stalled framed in to a wall or simply hung on the wall. - Page 7 Recessed Installation: 1. Prepare frame opening according A40CLX 25” W x 19 3/4” H x 4” D to chart. A60CLX 45” W x 19 3/4” H x 4” D A100CLX 85” W x 19 3/4” H x 4” D 2. Attach L-metal brackets to the fire unit with the provided small washer head screws.
- Page 8 Wall-hung Installation: 1. Hang the mounting bracket with the included large washer head screws and wall anchors. Wall an- chors should be used at the highest outside corners. Be certain that at least two screws are driven in to solid backing.
-
Page 9: Operation
Operation On the bottom of the unit is a main power switch. Switch this on to begin using the fireplace. Directly below the flame, on the right hand side are 3 small LED status lights and 3 buttons. Power Heat Backlight When all indicator lights are off, pressing on any button will only show... -
Page 12: Frequently Asked Questions
Frequently Asked Questions Q. How do you program the remote control? A. The remote comes pre-programmed. No programming is necessary. Q. What distance can the remote be used from the fireplace? A. Optimal distance for the remote control is within 10 yards. Q. -
Page 13: Troubleshooting
Troubleshooting SYMPTOM PROBLEM TEST SOLUTION Appliance turns off Appliance has overheated Unplug the appliance, allow and will not turn on and safety device has appliance to cool for 15 caused the thermal switch minutes, then plug it back to disconnect House circuit breaker has Reset house circuit breaker tripped... - Page 14 Notes...
- Page 15 Notes...
- Page 16 © 2011...
