Uniform user management.
Agile charge method.
User bandwidth and priority control base on RADIUS.
Use standard switch struct, can expand to other non-ethernet module.

1.3 S6508 Switch View

S6508 Switch is a 10-slot vertical chassis. Figure 1-1 shows the S6508 Switch chassis.
（1）
（2）
（3）
（4）
（5）
(1)Airflow exhaust: the system module air exhaust.
(2)Fan Assembly: the system fan assembly, 6 fans support.
(3)system module slot: 10 system module slots, support 10 system module.
(3)Airflow intake: the system module air inlet.
(4)Power supply slot: support AC-Power module or DC-Power module.
Figure 1-1 BDCOM S6508 Switch View
BDCOM S6508 Switch Hardware Installation Guide
- 2 -
