Brickcom FB-100Ap Series Hardware User Manual page 9

Photo Indication & Dimension Diagram
FB-H Series
NOTE
1. The WPS buttons must first be enabled through the web GUI in order to work. See
page for details on how to enable the WPS Button.
2. (*) These are optional features. Please refer to the Product List for the full list of optional
features available for the product.
Light Sensor
WPS LED
(WIFI series)
Status LED
Build-in
Microphone
Power Connector (DC12V In)
TV Out
Ethernet RJ45
(Link/Power LED embedded)
USB Port
Micro SD/SDHC/SDXC slot
DIDO Terminal I/O Connector
Audio Out
Auto Iris Connector
Microphone/Line In
Function (FocusEasy/ Reset)
8
**
- (W)FB-300Np V5 Series Only
Power Connector (DC12V In)
Power Connector (AC24V In)
Ethernet RJ45 10/100 Socket
(Link/Power LED embedded)
Antenna Connector
WPS Button (WIFI series)
USB Port
TV Out
Micro SD/SDHC/SDXC Card Slot
DIDO Terminal I/O Connector
Audio Out
Auto Iris Connector
Microphone/Line In
FocusEasy/Reset Button
WPS
**
