Chapter 3- Device Appearance Description

Photo Indication & Dimension Diagram
FB Series
Status LED
Light Sensor
WPS LED (WIFI
series)
Build-in Microphone
**
- WDRPro & STD Series not included
Light Sensor
CS Ring
Screw Holding
Auto Iris Connector
7
Power Connector
(DC12V In)
Power Connector
**
(AC24V In)
Detachable Antenna
(WIFI series)
Ethernet RJ45 10/100 Socket
(Link/Power LED embedded)
WPS Button
(WIFI Series)
SD/SDHC Card Slot
Extension I/O Terminal
Block
Audio Out
Microphone/Line In
Reset Button
PAL/NTSC
Function (FocusEasy/ Reset)
Monitor (TV out)
Power Connector (DC12V in)
USB Port for 3D Dongle
Ethernet RJ45 Socket
DIDO Terminal I/O Connector
Audio Out
Microphone/Line In
Micro SD/SDHC/SDXC slot
