- Page 1 COLORADO175...
- Page 2 CONTENT CONTENT ---------------------------------------------------------------------------------------------------------------------------------1 IMPORTANT SAFETY PRECAUTIONS -------------------------------------------------------------------------------------2 MAIN TECHNICAL PARAMETERS AND PRODUCT OVERVIEW ---------------------------------------------3 ASSEMBLY INSTRUCTIONS -------------------------------------------------------------------------------------------------4-6 FOLDING & UNFOLDING INSTRUCTIONS ------------------------------------------------------------------------------7 GROUNDING METHODS ----------------------------------------------------------------------------------------------------------8 OPERATION GUIDE --------------------------------------------------------------------------------------------------------------9-13 GETTING STARTED GUIDE ----------------------------------------------------------------------------------------------------14 SAFETY EXERCISES ---------------------------------------------------------------------------------------------------------------15 WARM-UP EXERCISES -----------------------------------------------------------------------------------------------------------16 MAINTENANCE INSTRUCTIONS --------------------------------------------------------------------------------------------17 BELT ADJUSTMENT ----------------------------------------------------------------------------------------------------------------18...
-
Page 3: Important Safety Precautions
IMPORTANT SAFETY PRECAUTIONS WARNING: Before starting any exercise program, consult with your physician or health professional， especially the person who is above 35 years old people or has some health problems before. We take no responsibility for any troubles or hurts due to above reasons. Don't power on until you finish assembly the treadmill and covering the protected top of motor. -
Page 4: Product Overview
The main technical parameters Input supply voltage：240V Working temperature: 0-40 ℃ Speed range: 0.8-16KM/H Incline range:15 level Motor incline Max. user weight: 120kg Distance display range: 0.00-99.9km Calories display range: 000-999 Time display range: 00：00-99：59 (min : sec) Heart rate range: 50-200 (time / min) Running surface: 460*1350mm Product size: 1750*760*1410mm Folding size: 1010*765*1540mm... - Page 5 WHEN YOU OPEN THE CARTON, YOU WILL FIND THE BELOW SPARE PARTS: Main frame 1set D21 Inner washer M8 D13 Round hex bolt C13 Safety Key 1set 8 pcs M8*15 4pcs D2 Allen wrench 6MM, D3 Allen wrench 5MM, D1 Screw driver 1 pc D16 Round hex bolt 1 pc 1 pc...
- Page 6 STEP 3: According to the picture, tighten the bottom frame with bolt M8*45(D16) and inner washer(D17). Then locked the console frame with M8*15 (D13) and inner washer (D17). Step 4: Attach the left/right side covers (B11L)&(B11R) to the base frame with bolt ST4.2*19 (D48) as picture.
- Page 7 Step 5: Put on the safety key (C13), MP3 Line (C19) and put on the bottle holder(B49) on the console. Step 6: To check if the running belt runs correctly, placing treadmill in folding position and tightening all the bolts. Then set speed under 3km/h and see if running belt runs without problem. ATTENTION: Must confirm complete assembly as the required above and lock all bolts.
- Page 8 Lift up the machine and force to pull up until you heard "click" that made by safety casing stuck the pneumatic cylinder. Kick the safety sleeve lightly and pull down the machine at the same time as the arrow direction. Then the machine will fall down smoothly.
- Page 9 This product must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This product is equipped with a cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.
- Page 10 1.1 WINDOW DISPLAY 1.2. START Normal start after 5 seconds countdown 1.3 PROGRAM 1 manual mode，12 re-set programs, 1 body fat program,3 countdown function and 3 users. 1.4 SAFETY LOCK FUNCTION The window shows"---" when take away the safety lock and the treadmill will stop quickly with "didi" alarm noise.
- Page 11 1.5.2 “PROGRAM” BUTTON When the treadmill is not running, press this button can circle choose from manual mode to pre-set mode P1-P12, body fat program, 3 countdown function, U1-U3. 1.5.3 “MODE” BUTTON When the treadmill is not running, press this button to choose countdown modes:”H-1”,”H-2”,”H-3”, “H-1”...
- Page 12 1.6.7 ALL WINDOW DISPLAY DATA RANGE TIME：0:00 – 99.59(MIN) DISTANCE: 0.00 – 99.9(KM) CALORIES: 0.0 – 999 (C) SPEED:0.8-16.0(km/h) PULSE: 50 – 200 (BPM) INCLINE：0 – 15 1.7 PULSE FUNCTION When the treadmill is running, hold the hand pulse about 5 seconds, it will display pulse data. The pulse data range is 50-200 times/ minute.
- Page 13 SPEED INCLINE 1.9 Manual model operation 1.9.1 Press start key, time count down 5 seconds, then treadmill will start to work with initial speed1km/h 1.9.2 Press speed +/-, you can adjust the speed 1.9.3 Press incline+/-, you can adjust the incline 1.9.4 Press stop, you can stop treadmill at working state 1.9.5 Press quick speed key, you can quickly adjust the speed you want 1.9.6 Press quick incline key, you can quickly adjust the incline you want...
- Page 14 1.12 User Program Besides 12 pre-set programs, there have 3 user-defined programs: U1, U2 and U3 Each user program has 10 segments. The user can set the desired speed and incline .Press "PROGRAM" button to choose U1 ,U2 or U3,press "MODE" button to enter setting condition, then set the time of the first segment. Press "SPEED+" and "SPEED-"...
- Page 15 PREPARE f you are around 35 years old, or have health problem, even this is your first time to do fitness exercise, please consult doctor or professional before use it. Before you exercise, please stand on the side to learn how to operate, such as start, stop and speed adjustment. After that stand on the plastic deck of the treadmill board, catch hold of the handrail, start by 1.6--3.2 km/h low speed, stand straight, look forward, one foot try to do few times, then stand on the belt to do exercise.
- Page 16 Please consult professional staff before starting an exercise program. They can help recommend the exercise rate / intensity and time according to your age and health condition. When running, if you feel chest tightness or chest pain, irregular Heartbeats, short of breath, dizziness or other unwell, please stop immediately! And consult professional before you want continually to do exercise.
- Page 17 It is better to do some warm-up exercise. Warm the muscle easy stretch, so use 5-10 mins to warm-up. Then stop and according below method to do stretch exercise for five times, and each foot do 10 seconds or more every time. After running, do those stretch exercises again.
- Page 18 WARNING：Please make sure pull out the treadmill's power plug before cleaning or maintaining the product. CLEANSING：General cleaning or the unit will greatly prolong the treadmill's life. Keep treadmill clean by dusting regularly. Be sure to clean the exposed part of the deck on either side of the walking belt and also the side rails.
- Page 19 Place treadmill on a level surface. Make treadmill run at approximately 6-8 km/h, observe the running belt deviate condition. f the belt has drifted to the right, unplug the safety lock and power switch, and turn the right adjusting bolt 1/4 turn clockwise, then insert the power switch and safety lock, make the treadmill running, observe the running belt deviate condition.
-
Page 21: Parts List
Parts list A. Welding parts Description Description Base frame Incline frame Main frame Filter supporting frame Left upright Motor bracket Right upright belt adjustment part Handrail bracket B. Plastic parts Description Description Console set Motor upper cover B1-1 Overlay Motor back cover B1-2 Membrane Key Side rail... - Page 22 Motor belt Magnetic ring Power switch Inductor Controller Filter Handle pulse left keyboard Single cord (black) 300 Handle pulse right keyboard Photoelectric Sensor Incline motor Single cord(CE) D. Hardware parts Description Description Screw driver 13-15-17 Spring washer M8 Allen wrench T6 Hex round head bolt M6*45 Allen wrench T5 Hex round head bolt M8*20...
-
Page 23: Error Code And Significance
Error code and significance Error Code Fault Description Solutions 1. Check if computer is connected to controller with correct wires, Failure communication check connector, check if wire is damaged, or unplug and between controller and re-connect computer 2. Change inverter and test 3. - Page 24 BODYWORX BODYWORX Model No: COLORADO175 To register your warranty, please go to www.gpisports.com.au...
