  • Page 1 BODYWORX JTM2000 TREADMILL Model No: JTM2000 WARNING THE BELT COMES PRE-LUBRICATED NO LUBRICATION REQUIRED Retain this owner’s manual for future reference. Read and follow all instructions in this owner’s manual.

  • Page 2: Table Of Contents

    CONTENT PAGE WARRANTY REGISTRATION FORM IMPORTANT SAFETY INSTRUCTIONS SAFETY GUIDELINES PRODUCT OVERVIEW ASSEMBLY INSTRUCTIONS FOLDING INSTRUCTIONS GROUNDING METHODS OPERATION GUIDE 12-17 GETTING STARTED GUIDE SAFETY EXERCISE 20 -21 EXERCISE INSTRUCTIONS BELT ADJUSTMENT EXPLODED DRAWING PART LIST 24-25 ERROR CODE AND SIGNIFICANCE...

  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Before beginning any fitness program, you should obtain a complete physical examination from your physician. This exercise equipment is designed and built for optimum safety for home use. However, certain precautions always apply whenever you operate any exercise equipment. Be sure to read the entire manual before assembly and operation of this machine.

  • Page 5: Safety Guidelines

    SAFETY GUIDELINES Successful fitness training programs have one prominent feature in common...safety. Fitness training has some inherent dangers, as do all physical activities. The chance of injury can be greatly reduced or completely removed by using correct techniques, proper breathing, maintaining equipment in good working condition, and by wearing the appropriate clothing.

  • Page 6: Product Overview

    The main technical parameters Input supply voltage: 240V Working temperature: 0-40 ℃ Speed range: 0.8-16KM/H Incline range: 15 level motor incline Max. user weight: 125kg Distance display range: 0.00-99.9km Calories display range: 000-999 Time display range: 00：00-99：59 (min : sec) Heart rate range: 50-200 (time / min) Running surface: 460*1350mm Product size: 1750*760*1410mm...

  • Page 7: Assembly Instructions

    WHEN YOU OPEN THE CARTON, YOU WILL FIND THE BELOW SPARE PARTS: Main frame 1 set D21 Inner washer M8 D13 Round hex bolt C13 Safety key 1 set 8 pcs M8*15 4 pcs D2 Allen wrench 6mm, D3 Allen wrench 5mm, D1 Screw driver 1 pc D16 Round hex bolt M8*45 4 pcs...
  • Page 8 STEP 3: According to the picture, tighten the bottom frame with bolt M8*45 (D16) and inner washer (D17). Then lock the console frame with M8*15 (D13) and inner washer (D17). Step 4: Attach the left/right side covers (B11L) and (B11R) to the base frame with bolt ST4.2*19 (D48) as shown in the picture below.
  • Page 9 Step 5: Attach the safety key (C13), MP3 Line (C19) and put on the bottle holder (B49) on the console. Step 6: To check if the running belt runs correctly, place the treadmill in folding position and tightening all the bolts. Then set speed under 3km/h and see if running belt runs without any problems.

  • Page 10: Folding Instructions

    Lift up the machine up from back until you heard "click" that made by safety casing stuck the pneumatic cylinder. Kick the safety sleeve lightly and pull down the machine at the same time as the arrow direction. Then the machine will fall down smoothly.

  • Page 11: Grounding Methods

    This product must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This product is equipped with a cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.

  • Page 12: Operation Guide

    Operation Guide 1.1 WINDOW DISPLAY 1.2. START Normal start after 5 seconds countdown. 1.3 PROGRAM 1 manual mode,15 pre-set programs, 1 body fat program, 3 countdown function and 3 users. 1.4 SAFETY LOCK FUNCTION The window shows"---" when take away the safety lock and the treadmill will stop quickly with "didi" alarm noise.
  • Page 13 1.5.2 “PROGRAM” BUTTON When the treadmill is not running, press this button and choose from manual mode to pre-set mode P1-P15, body fat program, 3 countdown function, U1-U3. 1.5.3 “MODE” BUTTON When the treadmill is not running, press this button to choose countdown modes:”H-1”,”H-2”,”H-3”, “H-1” is the time countdown mode, and “H-2”...
  • Page 14 1.6.7 ALL WINDOW DISPLAY DATA RANGE TIME：0:00 – 99.59 (MIN) DISTANCE: 0.00 – 99.9 (KM) CALORIES: 0.0 – 999 (C) SPEED:0.8-16.0(km/h) PULSE: 50 – 200 (BPM) INCLINE：0 – 15 1.7 PULSE FUNCTION When the treadmill is running, hold the hand pulse about 5 seconds, it will display pulse data. The pulse data range is 50-200 times/minute.
  • Page 15 SPEED INCLINE 1.9 Manual model operation 1.9.1 Press start key, time count down 5 seconds, then treadmill will start to work with initial speed 1km/h. 1.9.2 Press speed +/-, you can adjust the speed. 1.9.3 Press incline +/-, you can adjust the incline. 1.9.4 Press stop, you can stop treadmill at working state.
  • Page 16 1.12 User Program Besides 15 pre-set programs, there have 3 user-defined programs: U1, U2 and U3 Each user program has 10 segments. The user can set the desired speed and incline. Press "PROGRAM" button to choose U1 ,U2 or U3, press "MODE" button to enter setting condition, then set the time of the first segment.
  • Page 17 After finishing the setting of HRC data, user can press “MODE” key to modify the time. When “TIME” window flashes, it displays the default time as 30:00 minutes, and user can press “SPEED+/-“ to set up time. 1.13.3 Enter “START” key to begin the workout (Remember only can press “START” key after all setting is completed).

  • Page 18: Getting Started Guide

    PREPARE If you are around 35 years old, or have health problem, even this is your first time to do fitness exercise, please consult doctor or professional before use it. Before you exercise, please stand on the side to learn how to operate, such as start, stop and speed adjustment.

  • Page 19: Safety Exercise

    Please consult professional staff before starting an exercise program. They can help recommend the exercise rate/intensity and time according to your age and health condition. When running, if you feel chest tightness or chest pain, irregular Heartbeats, short of breath, dizziness or other unwell, please stop immediately! And consult professional before you want continually to do exercise.

  • Page 20: Exercise Instructions

    EXERCISE INSTRUCTIONS Using your exerciser will provide you with several benefits, it will improve your physical fitness, tone muscle and in conjunction with a calorie controlled diet help you lose weight. 1. THE WARM UP PHASE This stage helps get the blood flowing around the body and the muscles working properly. It will also reduce the risk of cramp and muscle injury.
  • Page 21 EXERCISE INSTRUCTIONS 3. THE COOL DOWN PHASE This stage is to let your Cardio Vascular System and muscles wind down. This is a repeat of the warm up exercise e.g. reduce your tempo, continue for approximately 5 minutes. The stretching exercises should now be repeated, again remembering not to force or jerk your muscles into the stretch.
  • Page 22 Place treadmill on a level surface. Make treadmill run at approximately 6-8 km/h, observe the running belt deviate condition. f the belt has drifted to the right, unplug the safety lock and power switch, and turn the right adjusting bolt 1/4 turn clockwise, then insert the power switch and safety lock, make the treadmill running, observe the running belt deviate condition.

  • Page 24: Belt Adjustment

    Parts list A. Welding parts Description Description Base frame Incline frame Main frame Filter supporting frame Left upright Motor bracket Right upright Belt adjustment part Handrail bracket B. Plastic parts Description Description Console set Motor upper cover B1-1 Overlay Motor back cover B1-2 Membrane Key Side rail...
  • Page 25 Cylinder MP3 line Motor belt Magnetic ring Power switch Inductor Controller Filter Handle pulse left keyboard Single cord (black) 300 Handle pulse right keyboard Photoelectric Sensor Incline motor Single cord (CE) D. Hardware parts Description Description Screw driver 13-15-17 Spring washer M8 Allen wrench T6 Hex round head bolt M6*45 Allen wrench T5...

  • Page 26: Error Code And Significance

    Error code and significance Error Code Fault Description Solutions 1. Check if computer is connected to controller with correct Failure wires, check connector, check if wire is damaged, or communication unplug and re-connect. between controller 2. Change inverter and test. and computer 3.
