Retain this owner's manual for future reference
Read and follow all instructions in this owner's manual
PROGRAMMABLE
BODYWORX SPORT
ROWER
3050 TREADMILL
Model No: KR6000PRO
Version A
SPORT3050
SPO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPORT3050 and is the answer not in the manual?

Questions and answers

Related Manuals for Bodyworx SPORT3050

Summary of Contents for Bodyworx SPORT3050

  • Page 1 PROGRAMMABLE BODYWORX SPORT ROWER 3050 TREADMILL SPORT3050 Model No: KR6000PRO Retain this owner’s manual for future reference Read and follow all instructions in this owner’s manual Version A...
  • Page 2 GPI Sports & Fitness Warranty Registration Form Congratulations on purchasing your product, we at GPI believe that our product range is of the highest quality and represents great value for money. We back our product range up with our industry leading warranty. Please see below for the step by step instructions on how to register your product warranty online.

  • Page 3: Table Of Contents

    CONTENT -------------------------------------------------------------------------------------------------------------------------------- CONTENT ----------------------------------------------------------------------------------3-4 IMPORTANT SAFETY PRECAUTIONS --------------------------------------------------------------------------------------------------5-7 ASSEMBLY INSTRUCTIONS ------------------------------------------------------------------------------8 FOLDING & UNFOLDING INSTRUCTIONS ----------------------------------------------------------------------------------------------------------9 GROUNDING METHODS -------------------------------------------------------------------------------------------------------------10-15 OPERATION GUIDE --------------------------------------------------------------------------------------------------------------16 SAFETY EXERCISES -----------------------------------------------------------------------------------------------------------18 WARM-UP EXERCISES --------------------------------------------------------------------------------------------19 MAINTENANCE INSTRUCTIONS ----------------------------------------------------------------------------------------------------------------20 BELT ADJUSTMENT -------------------------------------------------------------------------------------------------------------21 EXPLODED DRAWING -------------------------------------------------------------------------------------------------------------------------22-24 PARTS LIST ERROR CODE AND SIGNIFICANCE-----------------------------------------------------------------------------...
  • Page 4 The main technical parameters Working temperature: 0-40 ℃ Input supply voltage: 240V Speed range: 0.8-22.0 KH/M Incline range: 15 level Motor incline Max. user weight: 150kg Distance display range: 0.00-99.9km Calories display range: 000-999 Time display range: 00：00-99：59 (min : sec) Heart rate range: 50-200 (time / min) Running surface: 520*1520mm Product size: 1950*870*1450mm...

  • Page 5: Important Safety Precautions

    IMPORTANT SAFETY PRECAUTIONS WARNING: Before starting any exercise program, consult with your physician or health professional, especially if the person is above 35 years old people or has some health problems before. We take no responsibility for any troubles or injuries due to above reasons. Don't turn the power on until you finish assembling the treadmill and covering the protected top of the motor.
  • Page 6 removed. Note the power cord of motorised treadmill is made by special equipment, if it is broken, please contact distributor quickly. 15. The treadmill is for home use only. 16. The treadmill maximum user weight is 150kgs. 17. Please do not over exercise in order to avoid any injury and use caution when exercising on the treadmill for your safety.

  • Page 7: Assembly Instructions

    Assembly instruction WHEN YOU OPEN THE CARTON, YOU WILL FIND THE BELOW SPARE PARTS: D 21 Flat Washer M10 8 pcs D8 Round Head Hex Bolt A1 Main frame 1 set C13 Safety key 1 set M10*15 4 pcs D2 Allen Wrench T6, 1 pc C19 MP3 line 1 pc D1 Screw Driver 13-15-17 D12 Round Head Hex Bolt...
  • Page 8 STEP 2：According to the picture, tighten the bottom frame with Round Head Hex Bolt M10*55 (D12) and Flat Washer M10 (D21). Then lock the console frame with Round Head Hex Bolt M10*15(D8) and Flat Washer M10 (D21). Step 3: Attach the left/right side covers (B11L)&(B11R) to the base frame with bolt ST4.2*19 (D48) as picture.
  • Page 9 Step 5: Put on the safety key (C13), MP3 Line (C19) and put on the power cable (C15). Step 6: To check if the running belt runs correctly, place treadmill in folding position and tighten all the bolts. Then set speed under 3km/h and see if running belt runs without problem.

  • Page 10: Folding & Unfolding Instructions

    Folding instruction Lift up the rear of the machine and pull up until you hear a "click" that is made by the safety casing locking into position the cylinder. Unfolding instruction Push the safety sleeve lightly and pull down machine the same time as the arrow direction.

  • Page 11: Grounding Methods

    Grounding Methods This product must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This product is equipped with a cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.

  • Page 12: Operation Guide

    Operation Guide WINDOW DISPLAY 1.1. 1.2. START Normal start after 5 seconds countdown. 1.3 PROGRAM 1 manual mode，15 pre-set programs, 3 users, 1 body fat program,3 HRC. 1.4. SAFETY LOCK FUNCTION The window shows"---" when take away the safety lock and the treadmill will stop quickly with "didi" alarm noise. And put the safety lock on, the computer will display for 2 seconds and the date count down to “0”...
  • Page 13 1.5.3 “MODE” BUTTON When the treadmill is not running, press this button to choose countdown modes:”H-1”,”H-2”,”H-3”;:H-1” is the time countdown mode, and “H-2” is the distance countdown mode, “H-3” is the calorie countdown mode; press the “SPEED+/-” or “INCLINE+/-“button to adjust the data. After that, press the “START” button to start this treadmill. 1.5.4 “SPEED +/- “BUTTON SPEED +/–...
  • Page 14 Display the incline. 1.6.6 PULSE Display pulse data. 1.6.7 ALL WINDOW DISPLAY DATA RANGE TIME：0:00 – 99.59(MIN) DISTANCE: 0.00 – 99.9(KM) CALORIES: 0.0 – 999 (C) SPEED: 0.8-22.0(km/h) PULSE: 50 – 200 (BPM) INCLINE：0 – 15% 1.7 PULSE FUNCTION When the treadmill is running, hold the hand pulse about 5 seconds, it will display pulse data. The pulse data range is 50-200 times/ minute.
  • Page 15 1.9 MANUAL MODEL OPERATION 1.9.1 Press start key, time count down 5 seconds, then treadmill will start to work with initial speed 0.8km/h. 1.9.2 Press speed +/-, you can adjust the speed. 1.9.3 Press incline+/-, you can adjust the incline. 1.9.4 Press stop, you can stop treadmill at working state.
  • Page 16 The body FAT suits for any male and female to adjust the weight according together with other body quality index. The ideal FAT should be between 20-25, if under 19, it means too thin. If between 25 and 29, it means overweight, if over 30, it means obesity.
  • Page 17 1.13.3 Enter “START” key to begin the workout (Remember you can only press the “START” key after all the setting are completed. It’s suggested that user use wireless chest belt to detect the heart rate. If chest belt and hand pulse are used at the same time, data from chest belt will show up only on the screen. 1.13.4 During the operating of HRC, speed and incline will adjust as below: (1) If Target heart rate <THR-15, then the speed and incline will adjust automatically every 15 second, the SPEED will increase 0.8KM/h and incline add 1 section until they reach the max.
  • Page 18 Getting stared guide PREPARE If you are around 35 years old, or have a health problem, even if this is your first time to do fitness exercise, please consult doctor or professional before you use it. Before you exercise, please stand on the side to learn how to operate, such as start, stop and speed adjustment.

  • Page 19: Safety Exercises

    Safety Exercise Please consult professional staff before you exercise. He can help recommend exercise rate/ intensity and time according to your age and health condition. When running, if you feel chest tightness or chest pain, irregular heartbeats, short of breath, dizziness or feel unwell, please stop immediately! Consult a professional before you continue to exercise.

  • Page 20: Warm-Up Exercises

    Warm-up Exercise It is better to do some warm-up exercise. Warm up the muscles with easy stretches, so use 5-10 mins to warm-up. Then stop and according to the methods below to do stretch exercises five times, and each foot do 10 seconds or more every time. After running, do those stretch exercises again.

  • Page 21: Maintenance Instructions

    Maintenance Instruction WARNING： Please make sure you pull out the treadmill's power plug before cleaning or maintaining the product. CLEANING：General cleaning of the unit will greatly prolong the treadmill's life. Keep treadmill clean by dusting regularly. Be sure to clean the exposed part of the deck on either side of the walking belt and also the side rails.

  • Page 22: Belt Adjustment

    Belt Adjustment Place treadmill on a level surface. Make treadmill run at approximately 6-8 km/h, observe the running belt deviation. f the belt has drifted to the right, unplug the safety lock and power switch, and turn the right adjusting bolt 1/4 turn clockwise, then insert the power switch and safety lock, make the treadmill running, observe the running belt deviation.

  • Page 23: Exploded Drawing

    Exploded Drawing...

  • Page 24: Parts List

    Parts list A. Welding parts Description Description Base frame Running board tube Main frame Motor Bracket Left upright Belt guide Right upright A33L Left speaker network Handrail bracket A33R Right speaker network Incline frame Safety lock shrapnel Filter supporting frame B.
  • Page 25 Running belt Console upper wire Rear roller Console lower wire Front roller MP3 line Running board Magnetic ring Cylinder Inductance Motor belt Filter Power switch Overload protection Controller Single cord (blue) 300 Handle pulse left keyboard Speed Sensor Handle pulse right keyboard Single line (brown) 150 Incline motor Single branch (blue) 150...
  • Page 26 ST4.2*25 Cross self-tapping bolt Spring washer M5 ST3.5*16 Spring washer M8 Incline Shaft Bowl washer Round hex bolt M8*55...

  • Page 27: Error Code And Significance

    Error code and significance Fault Code Fault Description Fault Processing 1. Check the wires from the computer are connected to the Communication abnormal: The controller properly or if there is any damage to the cables. control and computer has 2. Check the controller and change it if it is damaged. abnormal communication after 3.
  • Page 28 BODYWORX SPORT PROGRAMMABLE ROWER 3050 TREADMILL Model No: KR6000PRO Model No: SPORT3050 To register your warranty, please go to www.gpisports.com.au...
