Summary of Contents for Bodyworx JX125
-
Page 2: Table Of Contents
INDEX 1. OVERVIEW DRAWING................2 2. IMPORTANT SAFETY INSTRUCTIONS ..........3 3. GROUNDING INSTRUCTIONS ..............4 4. PRE-ASSEMBLY CHECK LIST ..............5 5. ASSEMBLY STEPS ..................6 6. CAUTION ....................9 7. MAINTENANCE ..................10 8. COMPUTER OPERATION INSTRUCTIONS.......... 11 - 1 -... -
Page 3: Overview Drawing
1. OVERVIEW DRAWING Computer Safety Key/ Clip Power Switch Circuit Breaker Power Cord Frame Base - 2 -... -
Page 4: Important Safety Instructions
2. IMPORTANT SAFETY INSTRUCTIONS When using this product, basic precautions should always be followed, including the following: Please read the instruction carefully before starting to use this product. Danger – To reduce the risk of electric shock： Always unplug this product from the electrical outlet immediately after using and before cleaning the treadmill. -
Page 5: Grounding Instructions
3. GROUNDING INSTRUCTIONS The products must be grounded first. If malfunction or breakdown occurs, grounding will provide a path of least resistance for electric current to reduce the risk of electric shock. The product is equipped with a cord having an equipment-grounding conductor and a grounding plug. -
Page 6: Pre-Assembly Check List
4. PRE-ASSEMBLY CHECK LIST ITEM Description ITEM Description Frame Truss Hex Screw M8xP1.25x40 Left Decoration Cover Truss Hex Screw M8xP1.25x15 Right Decoration Cover Truss Philips Screw M5xP0.8x15 Cover-Left Hex Wrench + Screwdriver Cover-Right SILICON Cup Holder Safety Key/Clip Bottle... -
Page 7: Assembly Steps
5. ASSEMBLY STEPS 1. Don’t cut the strap before pick up the machine from the box as shown in the right pictures. Two persons are required to finish the assembly steps. (Caution!! Please follow exactly the assembly steps below to avoid injury.) Put up the two computer handrail tubes of Frame(A) as shown in the right drawing and tighten with hex screw(a). - Page 8 Then put up the left and right uprights as shown in the right drawing and tighten with hex screw(a and b). Ps. To avoid danger, always assemble the treadmill with more than two workers, do not assemble by yourself. 3. After tightened the left and right uprights, insert left and right decoration covers(B,C) onto frame respectively as the right drawing shows and tighten with Philips Screw(c)
- Page 9 4. Wedge cup holder(FG), left and right covers(E,D) onto the corresponding position as shown in the right drawing.
-
Page 10: Caution
CAUTION 1. This treadmill has the foldable mechanism for storage. Stop all the movements (including stop the running belt and take off the power cord) before storage, then pull out the POP-Pin of the folding fixing mechanism as the direction shown in the drawing and then lift up the frame. When doing this action, two persons need to operate together, one lift up the frame, the other pull out of the POP-Pin. -
Page 11: Maintenance
7. MAINTENANCE 1. If the belt tends to move off the center, stop the treadmill. Take the Hex Wrench and adjust the Hex Screw in the Rear End Cap. For example, if the running belt is moving towards the left side, tighten the left Hex Screw about 1/4 turn(clockwise);... -
Page 12: Computer Operation Instructions
Note: This maintenance intended household use. If used for business, it is suggested to examine the product every other month. 8. COMPUTER OPERATION INSTRUCTIONS eral Operation： 1. Turn on the treadmill Put the safety key in the recess of the console. The beeper will sound and all windows will display values, the initial values are 0, and not blinking, this present treadmill is under START/READY position, under this situation, user can... - Page 13 hold the grip pulse sensor to detect heart rate value directly. **If safety key/ clip doesn’t place in the recess of the console, the TIME window will display “----“, then the treadmill can’t be operated normally. **During work out, if the safely key/clip is off, then the beeper will sound for warning, then the treadmill will stop operation.
- Page 14 ** Check list below for different age and heart rate values： OVER MIDDLE (Age) 3. Press to start treadmill, the treadmill will start with a speed of 1.0km/hr, at this time press keys to increase/ decrease speed( also can press fast speed buttons to instantly choose the speed you need), press once to stop your workout( press...
- Page 15 start/ready status.
- Page 16 、 MODE operation instruction (Under this mode total have MANUAL and 6 PROGRAM installed program): MANUAL ： Under this mode, you can set up the time, distance as your need, operation method are as below ： 1.1. Press , when see the light of MANUAL LED light is blinking, press , then into the MANUAL mode.
- Page 17 Program pre-set 32 min Time range ： 5~99 min ， Step is 1 min 2.5 Regarding to the P1~P6 installed values, please refer to the last page Annex 1~ Annex 6 III、Body fat mode： 1. Under START/READY condition, press , you can see the Body Fat LED light is blinking, present you are in to Body Fat function.
- Page 19 Annex 1 P1-L1 P1-L2 P1-L3...
- Page 20 Annex 2 P2-L1 M IN...
- Page 21 Annex 3...
- Page 22 Annex 4 P4-L1 P4-L2 P4-L3...
- Page 23 Annex 5 P5-L1 P5-L2 P5-L3...
- Page 24 Annex 6 P6-L1 P6-L2 P6-L3...
