Bodyworx J4715 Owner's Manual

Bodyworx J4715 Owner's Manual

Motorised treadmill
Hide thumbs
Table of Contents

Advertisement

Quick Links

Motorised Treadmill
BODY WORX
BODY WORX
Model No: J4715
Retain this owner's manual for future reference
Read and follow all instructions in this owner's manual
Version A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the J4715 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bodyworx J4715

Summary of Contents for Bodyworx J4715

  • Page 1 Motorised Treadmill BODY WORX BODY WORX Model No: J4715 Retain this owner’s manual for future reference Read and follow all instructions in this owner’s manual Version A...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS *SAFETY PRECAUTIONS ------------------------------------------------------- 1 - 2 *BEFORE BEGINNING ------------------------------------------------------- 3 - 4 *FEATURES ------------------------------------------------------- *EXERCISE GUIDELINES ------------------------------------------------------- 6 - 7 *WARM-UP & COOL-DOWN ------------------------------------------------------- 8 - 9 *ASSEMBLY PART LIST ------------------------------------------------------- -------------------------------------------------------- *HARDWARE PACK *ASSEMBLY STEPS ------------------------------------------------------- 12 - 15 *FOLDING, UNFOLDING &...

  • Page 4: Safety Precautions

     SAFETY PRECAUTIONS Thank you for purchasing our products. Even though we have gone to great efforts to ensure the quality of each product, occasional errors, and/or omissions do occur. In any event should you find this product to be defective or missing a part, please contact the shop of purchase? Be sure to read the entire manual before assembly and operation.
  • Page 5  Any of the adjustment devices that could interfere with the user’s movement should not be left projecting.  Turn the switch off and unplug the power cord when the treadmill is not in use.  Incorrect and excessive exercise can harm your health. Before starting any exercise program consults your physician.

  • Page 6: Before Beginning

     BEFORE BEGINNING Clean your area: Remove the treadmill from the box and place on a flat surface. It is recommended that you place a protective covering underneath the treadmill. Place in an area that will meet minimum clearance requirements. Front &...
  • Page 7 IMPORTANT TREADMILL WARNINGS AND CAUTIONS In order to reduce the risk of fire, electric shock, burns or injury, please read and understand the following precautions before operating. DANGER: To reduce the risk of electric shock, always unplug this appliance from the electrical outlet immediately after use and before cleaning.

  • Page 8: Features

    Computer Console Hand Sensor Cantilever Mast Upright Post Motor Cover Foot safety lock Running Mat Rear Cover - 5 -...

  • Page 9: Exercise Guidelines

     EXERCISE GUIDELINES Any one over the age of 35, as well as younger people who are overweight, should check with their physician before beginning any type of exercise program. People who have diabetes or high blood pressure, a family history of heart disease, high cholesterol or have led a sedentary lifestyle should protect themselves with a medical check up and a stress test, preferably administered by a healthcare professional.
  • Page 10 EXERCISE IN YOUR TARGET HEART RATE ZONE BEGINNER TREADMILL PROGRAM Exertion level Duration Exertion level Duration WEEK 1 Easy 6 ~ 12 minutes WEEK 5 Moderate 22 ~ 28 minutes Slightly higher or WEEK 2 Easy 10 ~ 16 minutes WEEK 6 20 minutes slightly lower...

  • Page 11: Warm-Up & Cool-Down

     WARM-UP & COOL-DOWN A successful exercise program consists of a warm up, aerobic exercise and a cool down. Warming up is an important part of your workout, and should begin every session. It prepares your body for more strenuous exercise by heating up and stretching out your muscles. At the end of your workout, repeat these exercises to reduce soreness and cramping problems from your muscles.
  • Page 12 QUADRICEPS STRETCH With one hand against a wall for balance, reach behind you and pull your right foot up. Bring your heel as close to your buttocks as possible. Hold for 15 counts and repeat with left foot up. INNER THIGH STRETCH Sit with the soles of your feel together with your knees pointing outward.

  • Page 13: Assembly Part List

     ASSEMBLY PART LIST User manual Console Mast Cover Silicon and Power cord - 10 -...

  • Page 14: Hardware Pack

     HARDWARE PACK M5X15-4piece Safety key piece Safety key M8X15-4 piece ¦ µ piece ¦ µ ¦ µ piece 5 and 6 - 11 -...

  • Page 15: Assembly Steps

     ASSEMBLY STEPS STEP 1: Put console and console mast to right position as the following introduction. Attention: Please do not tighten the bolts. Facilitate the next step of assembly. - 12 -...
  • Page 16 STEP 3: ATTACH THE CONSOLE As shown, Connect the console wire and the mast wire, attached the console masts to the base frame, with φ8 washers and M8x15 and M8 x 40 bolts. Finally tighten all the bolts. Ø8 Washer M8×15 bolts M8×40 bolts Ø8 Washer...
  • Page 17 STEP 4: ATTACH CONSOLE TO THE CONSOLE MAST WITH M8 X 15 BOLTS. Ø8x24 Washer Ø8x24 Washer Ø8 Ø24 P ll M8x15 Bolt M8x15 Bolt - 14 -...
  • Page 18 STEP 5: ATTACH CONSOLE MAST COVER WITH M5 X 15 BOLTS. M5x15 Bolt M5x15 Bolt - 15 -...

  • Page 19: Folding, Unfolding & Moving

     FOLDING , UNFOLDING & MOVING INSTRUCTION FOLDING THE TREADMILL 1. Turn power switch to the OFF position. 2. Raise deck using the rear roller cover until unit closes completely. Important: You will hear a “click” sound when it has been closed completely. Store you treadmill in a clean and dry environment.

  • Page 20: Maintenance

     MAINTENANCE • Warning: To prevent electrical shock, be certain the treadmill is turned off and unplugged for cleaning or routine maintenance. • Important: Never use abrasives or solvents to clean the treadmill. To prevent damage to the computer, keep liquids away and keep it out of direct sunlight.
  • Page 21 CENTERING THE RUNNING BELT: When you run, you may step harder with one foot than with another. The severity of the deflection depends on the amount of force that one foot exerts in the relation to the other. The belt will often return to the center of the deck if weight distribution becomes balanced or nobody is on the running belt. If the running belt remains consistently off-center, you will need to center the running belt manually.
  • Page 22  TREADMILL LUBRICATION Lubricating under the tread belt will ensure superior performance and extend its life expectancy. Lubrication is available from your place of purchase. Wipe the entire deck surface with a clean lint free cloth to remove all dust and dirt. HOW TO CHECK RUNNING BELT FOR PROPER LUBRICATION Lift one side of the tread belt and feel the top surface of the running board If the surface is slick to the touch, then no further lubrication is required...

  • Page 23: Computer Instruction

     COMPUTER INSTRUCTION - 20 -...

  • Page 24: General Operation

     GENERAL OPERATION MANUAL MODE/QUICK START Press the key, the treadmill will start running at 0.8 km/h. You can set the speed by the speed setting key on the right side. Every Press of key on the right side, the speed will increase by 0.1 km/h. Press the speed key continuously the speed will increase rapidly to 12 km/h.
  • Page 25 Preset program 2 level speed incline Preset program 3 level speed incline Preset program 4 level speed incline Preset program 5 level speed incline Preset program 6 level speed incline - 22 -...
  • Page 26 CUSTOMER PROGRAM In this program user may also input the setting they preferred. Press may get into this program. The program is divided into 10 parts. Firstly, the distance window shows 01, means program setting come into the first part. You may set the speed and the incline of this part by the Key of speed and incline, then press the Key again, the second part of the whole program can be set,...

  • Page 27: Exploded Drawing

     EXPLODED DRAWING - 24 -...

  • Page 28: Parts List

    SPARE PART LIST ITEM Q’TY NO ITEM Q’TY ITEM Q’TY CONSOLE CYLINDER SELF-TAPING SCREW ST4.2×12 CONSOLE COVER TUBE CAP BOLT M6×12 (UPPER) CONSOLE COVER RUBBER DUCK RELAY (UNDER) BUFFER SET LIFTING MOTOR M8×16 TUBE CAP 20×40×1.5 RIGHT UP-RIGHT RUBBER BUFFER CONTROL BOX CUSHION POWER LINE...
  • Page 29 SELF-TAPING SCREW SIDE RAIL MOTOR ST4.2×12 FIXED AXIS BOLT M8×45 NUT M5×16 NUT M8 FRONT ROLLER BASE FRAME MOTOR v .BELT WHEEL BOLT M10×50 WHEEL COVER HANDLE BAR FOAM NUT M10 CONSOLE BRACKET LEFT UP-RIGHT COVER BOLT M6×60 MOTOR COVER ( upper ) TUBE CAP WASHER φ6 MOTOR COVER...

  • Page 30: Circuit Diagram

     CIRCUIT DIAGRAM - 27 -...

  • Page 31: Troubleshooting Guide

    TROUBLESHOOTING GUIDE ERROR CODE DESCRIPTION Er 1 Communication trouble Er 2 Control box trouble or Control box MOS tube trouble Er 3 Motor sensor connection trouble OR motor sensor trouble Incline trouble Er 4 Er 5 Voltage trouble Er 6 Current trouble - 28 -...
  • Page 32 BODYWORX BODY WORX...
