1.4 Front View

1. Locking faceplate — Use the included keys to lock the faceplate for
security, or to remove the faceplate to gain access to the drive bays.
2. LEDs indicators — See the chart below for details on the ThunderBay 4
mini's LEDs.
LED COLOR
BLUE/
Power
ORANGE
Drive
GREEN
(A, B, C, D)

1.5 Rear View

1. Thunderbolt ports — Attach the included Thunderbolt cable to one of
these ports and to your computer, or to another Thunderbolt device. Use
the other Thunderbolt 2 port to add more Thunderbolt devices to the chain.
2. DC input — Connect the included power supply here.
OWC THUNDERBAY 4 MINI
ThunderBay ThunderBay
ON SLEEPING
SOLID BLUE ORANGE
N/A OFF (ALL FOUR)
DRIVE BAD/
DRIVE
BAY EMPTY
ACTIVITY
N/A N/A
FLASHING
OFF
GREEN
3
2
1
1 2
