1.4 Front View

IMPORTANT: for units that ship with a drive pre-installed, the look and
placement of features will vary based on the brand and model. Not all drives
support Blu-ray or M-Disc
Eject button
Manual eject hole

1.5 Rear View

1. USB 3.1 Gen 1 port — Connect the included USB 3.1 Gen 1 cable here.
2. DC Power — Connect to the included power supply here.
3. Kensington
4. Power Switch — Use this switch to power the drive on or off.
OWC Mercury Pro
Manual eject hole
®
as shown above.
Press to open the disc tray.
If the disc tray cannot be opened by the eject button
or through software eject commands, insert a
straightened paper clip into the manual eject hole and
press to open the disc tray manually.
®
Security Slot — Connect a security tether here.
1
2
Eject button
3
2
4
